The LDI is a multiline, solid-state laser illuminator offering up to 1000mW of output power via a multimode fiber at the price of low power LED light engine. With

feedback controlled output stability and up to a 100:1 linear dynamic range, the LDI is the ideal light source for a wide range of applications including spinning disk confocal microscopy, structured illumination microscopy, FRAP, photoactivation/photoconversion, and PALM/STORM.

Features:

High output power
Shorter exposures
Faster Imaging
Faster activation times in optogenetics and photoactivation experiments
Faster bleaching times in FRAP experiments
Feedback controlled optical stability
Quantitative imaging, ideally suited for ratiometric imaging
More repeatable optogenetics experiments
Up to 100:1 linear dynamic range
Ability to turn power down when needed and maintain stability and quantitative imaging
Up to 7 lines
Covers most of the standard fluorescence probes
No user alignment
Easy to use and maintain
TTL and Analog control
No need for software specific drivers

Specifications:

Number of laser lines:6 or 7 lines, depending on the model
Laser wavelengths:
LDI-6 – 405/445/470/520/528/640
LDI-7 – 405/445/470/520/528/555/640
Output power:Out of 400 micron, 0.22 NA fiber
405 nm – 300 mW
445 nm – 1000 mW
470 nm – 1000 mW
520 nm – 500 mW
528 nm – 500 mW
555 nm – 1000 mW
640 nm – 500 mW
Lifetime:20,000 hrs – 2 year warranty
Stability:<1% RMS (at 100% laser power)
Dimensions:12.5″ x 9.2″ x 5.75″
