ABS 1 Cu. Ft. Glass Door Vaccine Refrigerator Left Hinged Certified to NSF/ANSI 456

These premier countertop refrigerators are designed in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. Refrigerators protect pharmaceuticals at optimal temperatures, preventing waste and allowing for peak delivery.

These glass door freestanding refrigerators utilize microprocessor controllers and feature temperature alarms, remote alarm contacts, LED interior lighting, and probe access ports with included probes.

American Biotech Supply Vaccine Storage Refrigerators utilize HFC-free refrigerant for environmental health and energy efficiency.

The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.

*-one or more of these certifications may apply to this unit.

Description

DESCRIPTION	SINGLE GLASS DOOR PHARMACY/VACCINE COUNTERTOP REFRIGERATOR LEFT HINGED FREESTANDING
OPERATIONAL ENVIRONMENT	INDOOR USE ONLY. OPTIMAL OPERATING RANGE: +18°C TO +26°C (+65°F TO +78°F), <70% RH
STORAGE CAPACITY	1 CU. FT. GROSS VOLUME
DOOR	ONE SWING GLASS DOOR, SELF-CLOSING, RIGHT HINGED, NON-REVERSIBLE, MAGNETIC SEALED GASKET, KEYED LOCK

SHELVES	THREE SHELVES (TWO ADJUSTABLE/ONE FIXED) WITH GUARD RAIL ON BACK
MOUNTING AND INSTALLATION	LEVELING LEGS. NOTE: 4" OF CLEARANCE ON ALL SIDES MUST BE MAINTAINED FOR ADEQUATE VENTILATION
INTERIOR LIGHTING	SHIELDED, SWITCHED LED LIGHTING, FULL COVERAGE, BALANCED SPECTRUM
AIRFLOW MANAGEMENT	FORCED AIR TECHNOLOGY, PATENT PENDING
EXTERNAL PROBE ACCESS	REAR WALL PORT (23/32") DIA.
INSULATION	CABINET IS FOAMED-IN-PLACE WITH EPA COMPLIANT HIGH DENSITY URETHANE FOAM
EXTERIOR MATERIALS	WHITE POWDER COATED STEEL
ACCESS CONTROL	PYXIS®, OMNICELL® AND ACUDOSE RX® COMPATIBLE
GENERAL WARRANTY	TWO (2) YEARS PARTS AND LABOR WARRANTY, EXCLUDING DISPLAY PROBE CALIBRATION
COMPRESSOR WARRANTY	FIVE (5) YEARS COMPRESSOR WARRANTY
EXTERIOR WIDTH	17 1/4"
EXTERIOR DEPTH	19 1/4"
EXTERIOR HEIGHT	21 1/4"
PRODUCT WEIGHT	66 LBS.
SHIPPING WEIGHT	94 LBS.
RATED AMPERAGE	0.9 AMPS
POWER PLUG/POWER CORD	NEMA 5-15 PLUG, 8 TO 10 FT TYPICAL, CONFORMS TO UL471 REQUIREMENTS, VACCINE STORAGE POWER CORD WARNING LABEL

FACILITY ELECTRICAL REQUIREMENT	110-120V AC: 15 A (MINIMUM)
AGENCY LISTING AND CERTIFICATION	CERTIFIED IN ACCORDANCE WITH THE NSF/ANSI 456 STANDARD FOR VACCINE STORAGE. UL, C-UL, ETL, C-ETL LISTED (EITHER SINGLE OR DUAL AGENCY LISTINGS) AND CERTIFIED TO UL471 STANDARD, HYDROCARBON REFRIGERANT SAFETY.
INCLUDED ACCESSORIES	TEMPERATURE MONITOR DEVICE (TMD) COMPLIES WITH THE CURRENT CDC GUIDELINES, WITH 3 YEARS CERTIFICATION OF CALIBRATION, “BUFFERED” PROBE IN THE PRODUCT SIMULATED SOLUTION, MIN/MAX MEMORY. FIELD INSTALLABLE, AND VISUAL & AUDIBLE TEMP ALARM PHARMACY REFRIGERATOR/FREEZER TOOLKIT AND TEMPERATURE LOGS

Performance

REFRIGERATION SYSTEM
COMPRESSOR	HERMETIC, HIGH PERFORMANCE
REFRIGERANT	EPA SNAP COMPLIANT, R600A, ISOBUTANE
CONDENSER	TUBE AND GRID CONSTRUCTION, FANLESS
EVAPORATOR	PLATE WALL
DEFROST	CYCLE OPTIMIZED, ZERO ENERGY

PERFORMANCE
UNIFORMITY¹ (CABINET AIR)	+/- 1.5°C
STABILITY² (CABINET AIR)	+/- 0.7°C
MAXIMUM TEMPERATURE VARIATION	+/-1.8°C
TEMPERATURE RISE AFTER AN AFTER 8 SEC DOOR OPENINGS	TEMPERATURE DID NOT EXCEED 6.8°C AT ANY PROBE FOR ALL REQUIRED NSF/ANSI 456 TESTING SCENARIOSᶟ
TEMPERATURE RISE AFTER AN AFTER 8 SEC DOOR OPENINGS
RECOVERY AFTER 3 MIN DOOR OPENING	ALL PROBES RECOVER TO UNDER 8°C WITHIN 5.5 MIN.
ENERGY CONSUMPTION	0.71 KWH/DAY⁴
AVERAGE HEAT REJECTION	1.01 KWH/DAY (237 BTU/H)⁴
NOISE PRESSURE LEVEL (DBA)	34 OR LESS INSTALLED
PULL DOWN TIME TO NOMINAL OPERATING TEMP	35 MIN
PULL DOWN TIME TO NOMINAL OPERATING TEMP

PERFORMANCE DATA ACQUIRED AT 22°C AMBIENT, USING NSF/ANSI 456 COMPLIANT VALIDATION BALLAST PROBES, EMPTY CHAMBER, DURING STABILIZED STEADY STATE OPERATION AND A DAQ SAMPLING RATE OF ONE MEASUREMENT EVERY 10 SECONDS

UNIFORMITY IS DEFINED AS THE MAXIMUM VARIANCE IN TEMPERATURE ACROSS ALL PROBES AT ANY POINT IN TIME OVER THE TESTING PERIOD
STABILITY IS DEFINED AS THE MAXIMUM VARIANCE IN TEMPERATURE EXPERIENCED BY ANY SINGLE PROBE OVER THE TESTING PERIOD
TEMPERATURE PERFORMANCE FOR ALL LOADED AND UNLOADED DOOR OPENING PROTOCOLS, ALL ALARM, CONTROLLER AND PROBE REQUIREMENTS AS DEFINED IN THE NSF/ANSI 456 STANDARD FOR VACCINE STORAGE
DATA PER ENERGY STAR TEST RESULTS OR EQUIVALENT TESTING AND CALCULATION. HEAT REJECTION BASED ON DAILY AVERAGES, NOT CONTINUOUS OPERATION. PERFORMANCE EXCEEDS ENERGY STAR REQUIREMENTS.

Temp Controller

CONTROLLER TECHNOLOGY	PARAMETRIC, MICROPROCESSOR, LED DISPLAY WITH 0.1°C RESOLUTION
TEMPERATURE SETPOINT RANGE	1°C TO 10°C (SETPOINT MUST REMAIN UNALTERED FROM THE FACTORY SETTING TO REMAIN COMPLIANT WITH NSF/ANSI 456 STANDARD FOR VACCINE STORAGE REQUIREMENTS)

DISPLAY PROBE	CALIBRATED, STAINLESS STEEL
EXTERNAL ALARM CONNECTION	STATE SWITCHING REMOTE ALARM CONTACTS
ALARMS	VISUAL AND AUDIBLE INDICATORS
	HIGH / LOW TEMPERATURE, COMPLIANT WITH ALARM REQUIREMENTS DEFINED IN THE NSF/ANSI 456 STANDARD FOR VACCINE STORAGE

SIMULATOR BALLAST	GLASS BEAD THERMAL MEDIA
