APC Smart-UPS 2200 Battery Backup Tower

Main Input Voltage

120V

Power Rating VA

1920 VA

Harmonic Distortion

5%

Features

Provides intelligent network power protection for servers, storage, and networking equipment

Features automatic voltage regulation (AVR) and noise filtering for consistent, clean power delivery

Managed outlet groups enable prioritized shutdown, remote reboot, and power conservation

Powered by durable lead-acid RBC55 batteries with a typical recharge time of 3 hours

Alphanumeric LCD display offers detailed system status and local configuration options

SmartSlot communication port supports accessory cards for advanced monitoring and control

Temperature-compensated charging extends battery life and improves performance

Compact tower design ensures easy deployment in server rooms or office environments

The APC Smart-UPS 2200 Battery Backup Tower offers intelligent network power protection, ensuring business continuity by delivering reliable, clean power to servers, storage, and network devices. Designed to safeguard critical data and equipment from power disruptions, this award-winning UPS provides network-grade power with advanced features like noise filtering, automatic voltage regulation (AVR), and surge protection. Its patented green mode ensures high efficiency at varying load levels, reducing utility and cooling costs, making it ideal for multi-core or virtualized servers.

This UPS delivers 1920 W (1920 VA) of reliable power, with a runtime of 7 minutes and 32 seconds at full load, powered by durable lead-acid RBC55 batteries. Featuring managed outlet groups, it allows segmented load control to prioritize critical equipment, reboot hung devices, or preserve battery power during extended outages. The system's intuitive alphanumeric LCD display provides detailed operational insights and local configuration capabilities, while SmartSlot™ communication ports enable integration with accessory cards for advanced monitoring and management.

With a compact design measuring 17.01 x 7.72 x 21.42 inches (43.2 x 19.6 x 54.4 cm) and a weight of 112.24 lb (50.91 kg), this unit is built for versatility and durability. Additional features such as temperature-compensated charging for extended battery life and a quick 3-hour recharge time enhance performance. The Smart-UPS ensures peace of mind with robust protection, efficiency, and manageability, allowing businesses to focus on growth rather than downtime.

All of our equipment is in excellent condition and will be fully tested to perform at factory specifications before being shipped.

INCLUDED:

The APC Smart-UPS 2200 Battery Backup Tower includes:

> Operator's Manual

> Full 180 Day Parts and Labor Warranty

APC Smart-UPS 2200 Battery Backup Tower Specifications

Main Input Voltage:	120V
Main Output Voltage:	120V
Kw Rating:	1920 W
Power Rating VA:	1920 VA
Output Frequency:	50/60 Hz ±3 Hz synchronized to mains
Harmonic Distortion:	5%
Run Time for Load:	7 min 32 s at 1920 W
Maximum Capacity Used:	100%
Input Connection Type:	NEMA 5-20P
Output Connection Type:	8 NEMA 5-15R, 2 NEMA 5-20R
Communication Port Type:	SmartSlot
Battery Power:	RBC55 batteries
Battery Type:	Lead-Acid
Typical Recharge Time:	3 hours
Battery Life:	3–5 years
Waveform Type:	Sine Wave
Efficiency at Full Load:	75...154 V adjustable / 82...144 V
Transfer Time:	4ms typical; 8ms maximum
Accoustic Level:	45 dBA
Thermal Dissipation:	275 Btu/H
Dimensions (H x W x D):	17.01 x 7.72 x 21.42 in. (43.2 x 19.6 x 54.4 cm)
Weight:	112.24 lb (50.91 kg)

Downloads

Technical Specification Download

Operator's Manual Download

Typically Ships Within: 3 to 5 Business Days
