The Thermo Scientific Forma 3110 Water Jacketed CO2 Incubator (Dual Stack) provides accurate CO2 control using either TC or IR sensors, temperature stability, and parameter recovery characteristics, with continuous contamination control technology.

Specifications (Based on nominal voltages of 115V or 230V in ambients of 22°C to 25°C):

- Temperature:
Control: +/-0.1°C
Range: +5°C above ambient to +55°C (131°F)
Uniformity: +/-0.2°C @ +37°C
Tracking Alarm User programmable high/low
- Temperature Safety:
Sensor: Precision thermistor
Controller: Independent analog electronic
Setability: 0.1°C
- CO2/O2
CO2/O2 Control: Better than +/-0.1%
CO2 Range 0-20%
O2 Range: 1-20%
Inlet Pressure: 15 PSIG (1.034 bars), m+/-5 PSIG
CO2 Sensor: T/C or IR
O2 Sensor: Fuel Cell
Readability: 0.1%
Setability: 0.1%
Tracking Alarm: User programmable
- Humidity:
RH: Ambient to 95% @ +37°C (98.6°F)
Humidity Pan: 0.8 gal. (3 liters) standard
Optional: Display in 1% increments
- Fittings
Fill Port: 3/8” barbed
Drain Port: 1/4” barbed
Access Port 1-1/4” (3.18cm) removable neoprene plug
CO2 Inlet: 1/4” hose barbed
- Unit Heat Load: 115V/230V 344 BTUH (100 Watt)
- Shelves:
Dimensions: 18.5” x 18.5” (47.0cm x 47.0cm)
Construction: Stainless steel, perforated, electropolished
Surface area: 2.4 sq. ft. (0.22 sq. m) per shelf
Max. per Chamber: 38.4 sq.ft. 3.6 sq. m)
Loading: 35 lbs (16kg) slide in and out, 50 lbs (23kg) stationary
Standard: 4
Maximum: 16
- Construction:
Water Jacket Volume: 11.7 gal. (43.5 liters)
Interior Volume: 6.5 cu. ft. (184.1 liters)
Interior: Type 304, mirror finish, stainless steel
Exterior: 18 gauge, cold rolled steel, powder coated
Outer Door Gasket: Four-sided, molded magnetic vinyl
Inner Door Gasket: Removable, cleanable, feather-edged, silicone
- Electrical:
115V Models: 90-125VAC, 50/60 Hz, 1 PH, 3.6 FLA
230V Models: 180-250VAC, 50/60 Hz, I PH, 2.0 FLA
Circuit Breaker/Power Switch: 6 Amp/2 Pole
Convenience Receptacle 75 Watts max. (one per chamber)
Alarm Contacts: Power interruption, deviation of temp., CO2, O2, and RH, customer connections through jack on back of unit. 30V, 1A max.
Optional Data Outputs: RS-485, 0-1V, 0-5V, 4-20mA
Installation Category: Overvoltage Category II; Pollution Degree 2
Maximum Leakage: Current With ground disconnected, 0.65mA; Maximum permissible leakage, 3.5mA
- Dimensions:
Interior (W x H x F-B): 21.3” x 26.8” x 20.0” (54.1cm x 68.1cm x 50.8cm)
Exterior (W x H x F-B): 26.3” x 39.5” x 25.0” (66.8cm x 100.3cm x 63.5cm)
- Weight (per unit):
Net: 265 lb. (120.2 kg)
Net Operational: 365 lb. (165.6 kg)
Shipping: 324 lb. (147.0 kg)
- Safety Specifications:
Altitude: 2000 meters
Temperature: 5°C to 40°C
Humidity 80% RH at or below 31°C, decreasing linearly to 50% RH at 40°C
Mains Supply Fluctuations: Operating Voltage Range
Installation Category: 2
Pollution Degree: 2
