MJ Research PTC-220 Thermal Cycler DNA Engine Dyad

The MJ Research PTC-220 Thermal Cycler DNA Engine Dyad cycler delivers multiblock thermal cycling with superior thermal performance. The programmable Dyad cycler with its dual-bay chassis is ideal for running multiple protocols and accommodating multiple users. Other features include: interchangable sample block capacity, Hot Bonnet heated lid for oil-free cycling or Power Bonnet lide for automated systems, intuitive software with user-friendly interface programming, and instant incubate feature for continuous-temperature incubation.

The MJ Research PTC-220 Thermal Cycler DNA Engine Dyad is in excellent condition and will be fully tested to perform at factory specifications before being shipped.

INCLUDED:

The MJ Research PTC-220 Thermal Cycler DNA Engine Dyad includes:

> 2 x 96-Well Alpha Block

> NIST Traceable Calibration Certificate

> Power Cord

> Operator's Manual

> Full 180 Day Parts and Labor Warranty

MJ Research PTC-220 Thermal Cycler DNA Engine Dyad Specifications

Thermal Range :	-5 to 105C, but no more than 30C below ambient temperature
Thermal Accuracy :	0.3C of programmed target at 90C- NIST-traceable
Thermal Uniformity :	0.4C well-to-well within 30 seconds of arrival at 90C (for most Alpha units; see specifications for individual Alpha Units)
Ramping Speed :	Up to 3C/sec for all single and dual-block Alpha units
Sample Capacity :	Varies with installed Alpha unit
Line Voltage :	200-240VAC
Frequency :	50-60Hz
Fuses :	Two 6.3A, 250V, 5 x 20mm
Displays :	One size VGA screen (320x240), 16 colors
Ports :	One 9-pin RS232 serial port, one Ethernet port
Memory :	8 MB
Weight :	11 kg
Size (L x W x H) :	48 x 29 x 15 cm

Thermal Cycler Inspection and Recertification Checklist

Validate that the power supply and PCB consistently deliver accurate, stable voltages across all circuits and connections, confirming operational reliability

Thoroughly inspect the display for any dim, flickering, or dead pixels, replacing compromised segments to ensure clear visibility and precise data display

Verify complete functionality and responsiveness of all buttons and knobs, confirming accurate and reliable input across all controls

Ensure the machine completes all internal diagnostic checks with zero errors, indicating system readiness and functional integrity

Confirm the machine accurately identifies attached blocks (96-well, dual 48, etc.), with seamless recognition across different configurations

Conduct a detailed inspection of internal wiring and all electrical connections, checking for any signs of breaks, disconnections, or tears; replace or repair any underperforming components

Examine the connector between the block and base for bent or broken pins, replacing as needed to maintain secure, reliable connections

Calibrate well temperatures with a NIST-traceable thermometer, verifying accuracy and uniformity across all wells to meet specification standards

Perform a comprehensive cosmetic inspection, ensuring all exterior surfaces and components are free of damage, wear, or defects, maintaining aesthetic and professional quality

Technician Inspection and Recertification Checklist: Thermal Cycler

The Following Checklist Is to Be Performed on All Incoming and Outgoing Pieces of Equipment

Task:	Completed?:	Remarks?
Validate stable, accurate voltage outputs from power supply and PCB across circuits:	Completed:
Inspect display for dim, flickering, or dead pixels; replace as needed for clarity:	Completed:
Verify functionality and responsiveness of all buttons and knobs:	Completed:
Confirm machine completes internal diagnostics with zero errors:	Completed:
Ensure accurate block identification across configurations (96-well, dual 48, etc.):	Completed:
Inspect internal wiring and connections for integrity; repair or replace as needed:	Completed:
Check connector between block and base for bent or broken pins; replace as necessary:	Completed:
Calibrate well temperatures with a NIST-traceable thermometer for accuracy:	Completed:
Conduct cosmetic inspection to ensure quality and professionalism of all surfaces:	Completed:

To View More of Our Recertification Protocol Click Here

Downloads

Technical Specification Download

Operator's Manual Download

Typically Ships Within: 7 to 10 Business Days

Free Shipping
