SCILOGEX D160 Homogenizer Package (volumes 1-250ml) Model # 850102019999

SCILOGEX D160 Homogenizer Package includes Drive Motor, DS-160/10 10mm dia. generator, flat head-open slot, 115mm immerse length, H-370 stand, for solid/liquid media, volumes 1- 250ml

The Scilogex D160 Homogenizer can rapidly homogenize, disperse, and emulsify samples in 0.1-50ml of liquid or 1-250ml depending on the generating probe. During operation, the suspended material is drawn into the core of the homogenizer by a rotor turning at up to 30,000rpm. The material is repeatedly cycled through narrow slits in the probe where it is rapidly sheared and disintegrated by high shear. Complete homogenization of tissues (muscle, liver, breast tissue, etc.) is usually achieved in a few seconds. Little, if any, heat is produced during the process.

Ideal for mixing, emulsification, shredding, or chopping
Practical answer for small samples
Saw Tooth generators for tissue homogenization available
Easy to hold and light weight for one hand operation
Generators are made of 316L Stainless Steel with PTFE bushings
Autoclavable stainless steel shafts. Inert to aggressive solutions
All shafts are interchangeable shafts and are easily removed for cleanup
High speed motor. Speed control from 8,000 to 30,000 rpm
Suitable for solvents & abrasive substances
2 YEAR WARRANTY

Specifications:

Speed range	:	8,000-30,000rpm
Sample volume range	:	0.1 - 250ml, tissue volumes 1-1000ml
Speed control	:	6 position control dial
Motor type	:	Universal motor, 130 Watt
pH range	:	2-13
Fineness	:	Suspensions & Emulsion 10-15 & 1-10um
Noise emission	:	< 54 dB(A) at 30,000 rpm
Dimensions	:	2.5L x 2.5W x 8H inches (drive only)
Weight	:	18lbs (with stand) 1.5lbs (drive only)
Voltage	:	110Volts, 60Hz
