Monochrome CMOS sensor with 1-inch optical format

1.7 megapixel camera with fast frame rates of 96 fps at full resolution (1608 x 1104)

Direct USB3 interface for fast image delivery and simplified connectivity

Compact form factor

Support for locking industrial micro USB on the back for power and control

INFINITY ANALYZE microscopy software included with purchase. No annual license fees. (camera requires INFINITY ANALYZE v7.0.3 or higher)

Software support for Windows and Mac, along with third-party plugins for MetaMorph and MicroManager

Selectable 8 or 12-bit pixel data

Recommended coupler: 1x

Outstanding Value for Fluorescence Imaging

The INFINITY8-2M is the new go-to microscopy camera for routine fluorescence imaging on a tight budget. With huge light-gathering pixels, large field of view, and low noise characteristics, this camera enables labs to have a dedicated monochrome camera for their low-light imaging requirements. And, with refresh rates of up to 96 fps at full resolution, the INFINITY8-2M provides exceptional low light sensitivity and allows for accurate imaging, even in variable lighting conditions.

Affordable solution

Today's climate of increasingly tight lab budgets and having to do more with less is challenging. Coupled with intuitive, feature rich software, owning a dedicated monochrome camera for routine fluorescence imaging is now possible - without the hefty price tag.

Need to replace a cooled camera?

The INFINITY8-2M is budget-friendly replacement for a cooled camera of the past that is no longer working, or not compatible with today's computers and software. This ultra-sensitive camera has large pixels and a 1-inch sensor, resulting in incredible sensitivity, lightning-fast speed, and with a large field of view. Take full advantage of a 1X coupler to see more.

FLIC for optimal responsivity

FLIC (Fluorescence Illumination Image Capture) reduces read noise and allows for maximum responsivity from the INFINITY8-2M. In low light imaging, the FLIC feature increases the sensitivity of the camera while keeping noise to a minimum. This is ideal for fluorescence imaging where small details can be difficult to make out, but require short exposures.

See more of your sample

See more of your sample than any other sensor size. Take advantage of your 1X coupler to eliminate extra cost.

Camera Sensor
Image Sensor	SONY IMX342; CMOS format, monochrome, 1.1” diagonal
Effective Pixels	1608×1104, 9μm square pixels
Frame Rate	96.3 fps maximum at full resolution in 8-bit or 12-bit mode
Signal/Noise	42.9dB in High conversion Gain mode (default); 50dB in Normal mode
Digital Output	8 or 12-bit
Read Noise	4.4 e- in High conversion Gain mode (default); 21.6 e- in Normal mode
Camera Controls
Mass	108g
Power Requirement	5V via Power Over USB3 Cable.
Power Consumption	~3.6 Watts
Operating Temperature	0° C to 50° C
Operating Humidity	10%-70%, Non-condensing
Integration Time	Programmable in increments of 1μs; minimum (in μs) is 14 μs maximum is 76 minutes; Pulse controlled via Trigger pulse width.
Shutter	Global Shutter
ROI	Full Frame
Exposure Mode	Automatic / Manual
White Balance	n/a
Gain	In-sensor Gain; 48 dB
Interface Connector	USB 3.1 connector, A-male to computer
Dimensions (L x W x H)	41.5 mm (max) x 45 mm x 45 mm
Lens Mount	C-Mount lens adapter
Binning Options	2 x 2

Product Includes:

I8-LM00-02M INFINITY8-2M – 1.7MP digital camera with 3m USB 3 cable (A-Male to Micro-B male Locking)

INFINITY user application software, TWAIN driver, Documentation
