Opti-Vision LED Light Boom Stand Boom Stand with Clamp ST02051205

Boom Stand.
Dia. 76mm Scope Holder.
Vertical Post Height: 384mm.
Vertical Post Diameter: Dia. 37.2mm.
Base Dimensions: 140x70x65mm.
Focus Distance: 50mm .
LED Light.
Light Adjustable.
Gooseneck Pipe Light.
Output Power: 5W.
Input Voltage: AC 100-240V 50/60Hz.
Output Voltage: DC 9V.

Specifications

Stand Type	Boom Stand
Vertical Post Height	384mm
Maximum Vertical Post Extended Length	254mm
Vertical Post Diameter	Dia. 37.2mm
Cross Adapter Type	Cross Hole Adapter
Horizontal Arm Type	Horizontal Post
Horizontal Arm Length	544mm
Horizontal Diameter	Dia. 37.2mm
Mounting Hole on the Top of Horizontal Arm	16mm
Horizontal Rotation Angle	360° Degree Rotatable
Horizontal Arm Travel Distance on Z-Axis	266mm
Horizontal Arm Stretch Range	487mm (19.173 in. )
Horizontal Arm Maximum Load	9.50kg (20.94lbs)
Horizontal Arm Travel Mode on Horizontal Direction	Manual
Horizontal Arm Travel Mode on Z Direction	Manual
Base Type	Clamp
Base Shape	Rectangle
Base Dimensions	140x70x65mm
Clamp Opening Size	0-40mm
Surface Treatment	Polished Chrome
Material	Metal
Color	Silver
Net Weight	9.6kg (21.2lbs)
Dimensions	544x70x405mm (21.417x2.756x15.945 in. )

E-Arm

76mm E-Arm
Holder Adapter Type	Dia. 76mm Scope Holder
Focus Distance	50mm
Coarse Focus Distance per Rotation	20mm
E-Arm Rotation Range on Horizontal Direction	360°
E-Arm Rotation Range on Z Direction	180°
E-Arm Mounting Adapter	5/8 in. End Adapter
Center Distance from E-Arm Adapter to Scope Holder	130mm
E-Arm Horizontal Adjustment Screw	Horizontal Adjustable
Safety Protection Against Falling Screw	With Safety protection against falling Screw
Surface Treatment	Spray Paint
Material	Metal
Color	White
Net Weight	0.84kg (1.85lbs)

Clamps and Stands

Clamp For Boom Stand Post
Vertical Post Diameter	Dia. 37.2mm
Base Mounting Size	M12x25mm
Clamp Opening Size	0-40mm
Surface Treatment	Electroplating Black
Material	Metal
Color	Black
Net Weight	0.85kg (1.87lbs)

Storage Tray

Mounting Bracket for Post(37.2mm Post)
Storage Tray Adapter Size	Dia. 37.2mm
Storage Tray Dimensions	11x4x2.1cm
Material	Metal
Color	Black
Net Weight	0.12kg (0.26lbs)
Applied Field	For Schott KL300-120.300-5W LED Fiber Optic Illuminator

Condenser

Adjustable Condenser
Condenser Type	Optical Fiber Condenser
Condenser Mounting Flange Size	Fastening Screw
Adapter Size	Dia. 5mm
Surface Treatment	Black Oxide Finish
Material	Metal
Color	Black

Fiber Optic Light Source

5W LED Fiber Optic Illuminator
Light Source Type	LED Light
Power Supply Adjustable	Light Adjustable
Light Source Luminous Flux	80 LM
Power Box Light Port	Single Hole
Fiber Cable Adapter Size	Dia. 9mm
Power Box Panel Meter Display	Pointer Panel Meter/Scale
Power Box Cooling System	Heat Sink
Power Box Dimensions	107x114x61mm
Bulb Color Temperature	5600K
Output Power	5W
Input Voltage	AC 100-240V 50/60Hz
Output Voltage	DC 9V
Material	Plastic
Color	White
Net Weight	0.35kg (0.77lbs)

Optical Fiber Light Guide

500mm Gooseneck Pipe Light
Optical Fiber Cable Type	Gooseneck Pipe Light
Fiber Cable Output Port Adapter Size	Dia. 5mm
Fiber Cable Input Port Adapter Size	Dia. 9mm
Pipe Material	Gooseneck Fiber Cable
Optical Fiber Cable Length	500mm
Pipe Diameter	Dia. 11mm
Pipe Color	Black
Material	Metal
Color	Black
