Bioptechs Oasis Cooling System 15-160

A precise, compact, recirculating chiller for laboratory use.

Reliable, Refrigerant-Free Thermoelectric Technology: With lifetimes exceeding 200,000 hours, the thermoelectric modules at the core of this chiller make for ultra-high intrinsic reliability
Fits Inside Your Equipment: UC160-190 is less than one-sixth the size of its nearest competitor, measuring7.5 x 5 x 7” (19 x 13 x 18 cm) and weighing only 8 lbs (3.5 kg)
Precise Temperature Control: UC160-190’s digital PID control holds to ±0.1 °C through a range of 2 to 45 °C, even near ambient
Easy Operation: Its standard, easy-to-use RS232 communications interface and digital controller for fixed temperature control or temperature cycling make operation of UC160-190 simple.
Energy Efficient: Less than one-fourth the power usage of the nearest competitor (<200 W AC power)
Air-cooled: Does not require house or facility chilled water. Can operate in any standard room, laboratory or office
Lower Heat Load: Available in capacities from 160-190 Watts, well below the economical range of refrigerant-based chillers
Versatile: Universal power input – so OEM’s need only one model for world-wide use. Multiple fluids: 27% propylene glycol solutions (preferred), ethylene glycol solutions

Operating Range:	2 to 45 °C: (160/180W models) 10 to 45 °C: (170/190W models)
Ambient Temperature:	10°C to 40°C non-condensing
Stabillity/Repeatability:	± 0.1°C with constant load (even near ambient)
Cooling Capacity:	160 to 190 Watts @ 20°C (20°C ambient)
Noise (at 1 meter):	< 63 dBA
Coolant / Process Fluid:	Koolance (27% propylene glycol / water mix) or 27-50% ethylene glycol / water mix
Process Fluid Fittings:	1/8″ female CPC quick connect with shut-off valve
Pump:	Magnetically-coupled gear pump with brushless DC motor
Tank Volume:	75 ml with level sensor (optional sealable cap)
Wetted Materials:	Aluminum + polymers or Copper + polymers
Size (L x W x H):	7.5″ x 5″ x 7″ (19 x 13 x 18 cm)
Weight:	8 lbs (3.5 kg)
Power Input:	Universal: 100-240 VAC, 50/60 Hz, 2.8 amps max
Power Consumption:	less than 200 Watts
Operating Voltage:	13.5 VDC, 15 amps max (universal input, laptop style power supply included)
Communications:	Keypad or RS232 interface
Alarms:	Temperature, fluid level, system or component failure (display, RS232 and dry contact)
Standards:	TUV listed to UL, CAN/CSA and EN 61010-1, CE 61010-1
Warranty:	1 year
