The Dräger Infinity Delta XL Patient Monitor is a versatile and high-acuity monitoring solution designed for continuous surveillance of adult, pediatric, and neonatal patients. Its robust feature set and seamless integration capabilities make it ideal for use in hospitals, surgical centers, and intensive care units, ensuring accurate and reliable patient data across various clinical settings.

Overview

Equipped with a 12.2-inch color TFT-LCD display, the Infinity Delta XL offers clear visualization of patient parameters, supporting up to 8 configurable waveforms. Standard monitoring features include 3-, 5-, 6-, and 12-lead ECG, non-invasive and invasive blood pressure (NIBP/IBP), SpO₂, pulse rate, respiration, temperature, and full arrhythmia analysis. Optional modules such as end-tidal CO₂ (EtCO₂), BISx™, EEG, and cardiac output provide flexibility to adapt to various patient care requirements. The integrated Pick and Go® technology allows the monitor to double as a transport monitor, ensuring continuous monitoring without interruption.

Key Features

12.2" color TFT-LCD display with up to 8 configurable waveforms
Standard monitoring: 3-, 5-, 6-, and 12-lead ECG, NIBP, IBP, SpO₂, pulse rate, respiration, temperature, arrhythmia analysis
Optional modules: EtCO₂, BISx™, EEG, cardiac output, ST segment analysis
Pick and Go® technology for seamless transition from bedside to transport monitoring
24 hours of trended parameter data storage with graphical and tabular displays
Seamless wired-to-wireless networking via Infinity Network and Infinity CentralStation
Compatibility with Masimo SET®, Nellcor OxiMax®, and Dräger OxiSure® SpO₂ technologies
User-friendly interface with customizable screen layouts and alarm settings

Product Specifications

Dimensions: 10.7" H x 15.1" W x 7.5" D (27.2 cm x 38.4 cm x 19 cm)
Weight: Approximately 13.6 lbs (6.2 kg) without external battery
Display: 12.2" color TFT-LCD, 800 x 600 pixels resolution
Battery: Rechargeable lithium-ion with up to 3 hours of operation; charging time approximately 6.5 hours
ECG: Up to 12 leads; heart rate range: 15 to 300 bpm; accuracy: ±2 bpm or ±1%
Respiration: Impedance pneumography; range: 0 to 155 breaths per minute; accuracy: ±1 breath/min or 2%
SpO₂: Measuring range: 1% to 100%; pulse rate: 30 to 250 bpm; accuracy: ±2% (70% to 100% SpO₂)
NBP: Oscillometric method; systolic, mean, and diastolic pressures; heart rate range: 30 to 240 bpm
IBP: Up to 8 pressures; measuring range: -50 to 400 mmHg; accuracy: ±1 mmHg
Compliance: Meets IEC60601 series standards

Ideal For

Hospitals and medical centers
Intensive care units (ICU)
Operating rooms and surgical suites
Post-anesthesia care units (PACU)
Emergency departments
Neonatal and pediatric care units

Warranty: 30 Days
Lead Time: 1-3 Days

Item Representation:

The item listed is a representative example of the make and model described. The exact unit shipped may vary slightly in appearance (e.g., cosmetic condition or minor wear) but will meet the same functional specifications and quality standards outlined in this listing. Serial number will be provided after sale.
