Description

Yamato DC401 with 12 Port Flask Mounting Chamber & 5 pcs. of 120ml Dry Flask with Straight Glass Joint and Cap

Features:

Automatic Leak System can prevent from Vacuum Oil’s Back Flow when the power turned off or breakout occurs.
Ice can be refrozen and removed smoothly from the vessel by Hot Gas Bypass System.
It’s loaded with Pirani Vacuum Gauge
Safety Valve is linked with Service Receptacle for Vacuum Pump
Little impact on global warming and the ozone layer by using non-CFC refrigerant

Specification

Performance
Trap Cooling Temp.	-45deg.C
Dehumidify Amount	0.6L
Time to Reach	50min. (+20 --> -45deg.C)
Components
Temperature sensor	None
Temperature display	None
Refrigerator	Air Cooling Type, 400W
Refrigerator, Coolant	R404A, Coolant Amount: 300g ±5g
Compound gauge	None
Bath Shape, Material	Cylinder Type
Drain	Vacuum Hose with Stopper
Exhaust port (vacuum pump connection)	φ17
Vacuum Gauge	Pirani Vacuum Measure
Service Receptacle	for Vacuum Pump Max 6A, for Heater Max. 2A
Trap Defrost	Defrosted by Hot Gas
Ambient temperature range	5～30deg.C
Safety Device
Safety Countermeasure	Electric Leakage Breaker with Over Current Protection, Refrigerator Overload Relay, Valve for Back Flow Prevention
Standard
Trap Dimensions	φ153 x H235mm
External Dimensions	W300 x D450 x H720mm
Internal Capacity	Approx. 4L
Power	AC100V, 50/60Hz, 6A (20A)
Power Code	1.6m
Suitable Vacuum Pumps Displacement	50/60L/min.
Weight	Approx. 43kg
