IKA Tube Mill control Disposable Chamber Grinding System

Motor Rating Input

100 W

Speed Range

5000 - 25000 rpm

Feed Hardness Max

5 Mohs

Features

The IKA Tube Mill control features a patented disposable grinding chamber, eliminating cross-contamination and cleaning efforts.

Transparent chamber allows observation of grinding tests; suitable for hard, dry, and brittle materials like seeds.

Emphasis on security with error messages for improper chamber insertion and secure drive unit.

Features multilingual OLED display, adjustable timer, USB interface, interval operation, and variable speed from 5000 to 25000 rpm.

Various operating modes, adjustable safety settings, and programmable test conditions ensure reproducible results.

Includes two grinding chambers (MT 40.10 and MMT 40.1), touch keypad for easy operation, and dust-proof sealed housing for quiet operation.

The Tube Mill control features single-use grinding chambers to eliminate cross-contamination and reduce cleaning efforts, with durable reusable chambers also available.

Supports many applications, including cryogenic grinding using minimal dry ice to embrittle materials, greatly expanding its capabilities.

Equipped with safety interlocks that prevent operation unless the hood and grinding chamber are properly secured.

Tube Mill control The world’s first patented Tube Mill control is a batch mill with disposable grinding chamber. Eliminates possibility of cross-contamination and the effort of cleaning. The grinding chamber and cover are made of a transparent material so grinding tests can be observed at any time. The mill can be used for hard (Mohs hardness up to 5), dry and brittle materials. It is especially suitable for grinding seeds, such as corn and wheat. During development of the mill, particular emphasis was placed on security. The mill will only start when the hood is closed. When the grinding chamber is not inserted properly or not closed properly, the drive unit will display an error message and the drive will not start. During operation, the grinding chamber cannot be opened. The drive and the grinding chambers are secured with a labyrinth seal. No dust can escape from the chamber or penetrate the drive. Clearly arranged, multilingual OLED-display Timer, adjustable from 5 s to 3 min USB interface for control and documentation of all the parameters Interval operation available Infinitely variable speed from 5000 to 25000 rpm Various operating modes Adjustable safety speed Adjustable safety time Programmable and storable test conditions Error Code Display Reproducible test results Easy operation with touch keypad Dust proof sealed housing Quiet operation Scope of delivery includes two grinding chambers: 1 x MT 40.10, 1 x MMT 40.1

INCLUDED:

The IKA Tube Mill control Disposable Chamber Grinding System includes:

> MT 40 milling tube, 40 ml

> MMT 40.1 Multi-use milling tube

> Coupling extractor

> USB A-B Cable

> Power Cord

> Operator's Manual

> One Year Manufacturer's Warranty ( + Additional Free 1 Year Warranty Extension with IKA Registration)

> Manufacturer's Documentation

IKA Tube Mill control Disposable Chamber Grinding System Specifications

Process type:	batch
Operating principle:	cutting/impact
Motor rating input:	100 W
Motor rating output:	80 W
Speed range:	5000 - 25000 rpm
Speed deviation:	±2 %
Circumferential speed max.:	65 m/s
Useable volume max.:	40 ml
Feed hardness max.:	5 Mohs
Feed grain size max.:	10 mm
Power-ON time:	3 min
Mill feed can be cooled in milling chamber with dry ice:	yes
Dimensions (W x H x D):	180 x 170 x 300 mm
Weight:	2.7 kg
Permissible ambient temperature:	5 - 40 °C
Permissible relative humidity:	80 %
Protection class according to DIN EN 60529:	IP 30
USB interface:	yes
Voltage:	100 - 120 V
Frequency:	50/60 Hz
Power input:	100 W

Downloads

Technical Specification Download

Operator's Manual Download

Manufacturer's List Price: $3,175.00

Typically Ships Within: 5 - 7 Business Days

Free Shipping
