Horiba ABX Micros 60 CS Hematology Analyzer

Includes:

One Horiba ABX Micros 60

Features:

• Measurement methods: Impedance technology, photometry.

• Liquid valves (without pinching): Reliability and increased precision

• No compressor (stepper motor): Reliability, less maintenance and noise

• 8 or 18 fully automated parameters

• CBC / 3 Part DIFF

• Open or Closed Tube

Specifications:

Weight

31 lbs

Power supply

90/240 V - 50/60 Hz - 230 VA.

Dimensions

16.5 in x 14 x 12.5 in (HxWxD).

Printer

Dot matrix.

Throughout

60 samples/hour (on open tube)
55 samples/hour (closed tube)

Data management

Automated smart cards used for QC and patient data storage (optional).
RS 232 output.
Mono-directional connection.

Memory

Last result (with curves) or 78 results (optional smart cards based memory)

Screen

2 lines of 40 alphanumerical characters.

Keyboard

Barcode reader (optional).

Samples

60 samples/hour (open tube)

Parameters (16+2)

CBC Mode (18 parameters): WBC, RBC, HGB, HCT, MCV,*RDW, MCH, MCHC, PLT, MPV, PCT, *PDW, % and # of LYM, MON and GRA

Graphics

LMG histogram, RBC, PLT histograms

Sample-Volume

CBC mode: 10 µL

Stability

24 hours (CBC)

Operating sample mode

Open tube mode with 4 position tube holder (QC, 125 or 500 µL, 3 or 5 mL)

Identification

Patient I.D., Sequence#

Flags

Pathological flags (WBC, RBC, and PLT) normal limits and counting failure flags

* RUO (Research Use Only)

Results

Parameters

Precision (cv %)

Linearity

WBC

< 2,5%

0-100 x 10³/mm3

RBC

< 2%

0-8 x 106/mm3

HGB

< 1.5%

0-26 g/dl

HCT

< 2%

0-80%

PLT (whole blood)

< 5%

0-2200 x 10³/mm3

PLT (PLT concentrate)

< 5%

0-4000 x 10³/mm3

International Diagnostic Equipment Refurbishment Protocol:

Our technicians decontaminate and clean equipment upon arrival at our facility and upon your purchase to create a neutral environment for your lab use.

Preliminary testing is then conducted on our equipment to identify potential defects. Upon completion, we replace all faulty and/or under-performing parts with original manufacturer parts that perform up to specification.

Any parts known to fail or malfunction on the piece of equipment are removed and replaced to insure the extended lifetime of your equipment.

Any necessary preventative maintenance is performed alongside repairs, so your purchase will be ready to go as soon as it arrives.

All of the electronics and boards are tested for proper function and response by our industry trained technicians. Any electronic deficiencies detected are immediately repaired.

Final testing cycles ensure your equipment performs fully at manufacturer specifications, guaranteeing you receive a properly working product ready for use.

Once we finish our rigorous testing and decontamination procedures, your order will be packaged to best protect it during shipment and may include delivery insurance depending on value.

* Free 30 day Returns

* Free Same Business Day Shipping

* Ebay Top Rated Plus Product

* This product is available also in different quantities and cases please ask us for details

International Diagnostic Equipment

- Call or email with your questions , Hablamos Español

- Ship from: IDE - Southern California. Global Shipping

- Details of item must be read carefully before buying and /or requesting return

Disclaimer:

"The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item."
