Product Description

Download Product Brochure

Schedule a Consultation

Ecodyst Hydrogen Sustainability Case Study

Available sizes: 3 Liters

Benchtop Rotovap Systems from Ecodyst

Engineered for convenient evaporation and concentration of samples where space is at a premium, the EcoChyll® X1 pioneers tankless evaporation technology for rotary evaporators. Based chemical resistant metallic coil condenser with completely stationary glassware, the EcoChyll® X1 provides an efficient and safe alternative to glycol chillers, dry ice or water condensers.

The compact smart self-cooling condenser is compatible with traditional rotary evaporators, with a footprint of less than 1 square foot meaning. The EcoChyll® X1 is designed to provide labs with a cutting-edge and powerful condenser solution for faster sample dry downs, including aqueous solutions. It can also be used as a cold trap for any other applications such as short path or concentrators.

EcoChyll X1 Smart-Cooling Chiller and Condenser

Cooling System Designed for:	Rotary evaporators and other distillation equipment
Upgrades Existing Rotary Evaporators:	Yes
Cooling Capacity	602 watts (-10C), 248 watts (-35C). See brochure below for complete cooling capacity chart
EcoChyll Technology:	Eliminates dry ice, recirculating chiller, and antifreeze and/or water. It has no consumables

Features:

Small footprint
Smart self-cooling condenser with chemically resistant coils and a huge surface area
Condenser is always available and eliminates recirculating chiller, antifreeze, dry ice, and water
No associated operational expenses
Eco-friendly energy efficiency
Designed for an extremely wide range of solvents, including water and all solvents used in the cannabis and hemp industries
Single user operation with minimal interference required

Specifications:

Equipment

Dimensions (approx.) – 12″ L x 12″ W x 29″ H

Electrical

Power cons. 645 watts
Available in both 115 and 220 Volts, 50/60 Hz

Technical

EcoChyll cooling capacity – Available on request
EcoChyll minimum temperature – -40°C
Metal parts – Stainless steel 316
Glass parts – Borosilicate glass
Condensation coils – coated with chemically-resistant fluoropolymer Halar
Sealing and tubing materials – PTFE and FEP
Warranty** – Two-Year Manufacturer (includes parts & labor, excludes all glass components)

EcoChyll A Small-Scale Lab Rotary Evaporator: Key Advantages

Best-in-class evaporation rates
Cost-effective by eliminating expensive rotary motor with overhead stirring
Easy-to-use, with simple product drainage not requiring removal of large evaporation vessels
Excellent energy efficiency
Space saving, with a low form factor
Safety guaranteed, with all glassware remaining stationary throughout operation

Ecodyst has pioneered a brand-new self-cooling technology designed to disrupt the traditional rotary evaporator (rotovap) market. The EcoChyll® S is one our proprietary tankless evaporator for low volume extractions, but the upcoming Ecodyst 1H is envisaged as the successor to the already successful EcoChyll® S.
