Yamato FP-103 High Performance Muffle Furnace 1.5L, 115V

Operating Temperature Range

100°C to 1150°C

Max. Temperature Reaching Time

~90 min.

Internal Capacity

1.5L

Features

RCF-free chamber

High-temperature accuracy at ±1.0°C

Upgraded with long-life R-thermocouple sensors

High accuracy controller for better operability and visibility

Excellent heat tightness with a firmly sealed chamber door

Program operation of maximum 99 steps, 99 patterns, with repeat operation function

High-quality alumina porcelain hot plate where the heater is not exposed to the inner chamber preventing contamination of samples

Safety features include self-diagnostic functions, calibration off-set, key lock function, auto-recovery after a power failure, earth leakage breaker, automatic overheat prevention device, and independent overheat prevention device

High performance 1.5L muffle furnace with a microprocessor-controlled thermo-regulator characterized by excellent repeatability and features temperature resistant paint. High accuracy controller for better operability and visibility. Excellent heat tightness with a firmly sealed chamber door. High temperature accuracy at ±1.0°C. Upgraded with long life R-thermocouple sensors. High quality alumina porcelain hot plate where heater is not exposed to the inner chamber preventing contamination of samples. Program operation of maximum 99 steps, 99 patterns, with repeat operation function. Safety features include self-diagnostic functions, calibration off-set, key lock function, auto recovery after power failure, earth leakage breaker, automatic overheat prevention device and independent overheat prevention device. Optional items include exhaust system, N₂ gas loading device (with flow meter), temperature output terminal, time-up output terminal, sample tray, external communication terminal (RS232C), external communication adapter, event output terminal, operation signal output terminal and furnace floor plate. Temperature range 100°C or 1150°C.

INCLUDED:

The Yamato FP-103 High Performance Muffle Furnace 1.5L, 115V includes:

> Exhaust port cap, fuse, furnace floor plate

> Power Cord

> Operator's Manual

> Manufacturer's Documentation

> 1 Year Manufacturer's Warranty

Yamato FP-103 High Performance Muffle Furnace 1.5L, 115V Specifications

Operating temp. range:	100~1150°C
Temp. control accuracy:	±1.0°C (at 1150°C)
Temp. fluctuation:	±1.0°C (at 1150°C)
Temp. distribution accuracy:	±4.0°C (at 1150°C)
Temp. gradient:	14°C (at 1150°C)
Max. temp. reaching time:	~90 min.
Exterior material:	Cold rolled steel plate with baked-on melamine resin finish
Interior material:	Alumina fiber
Sensor:	R-thermocouple
Heater:	Iron-chrome wire - 1.1kW
Exhaust port:	ø20mm (top)
Cooling fan:	19/16W (50/60Hz)
Temp. controller:	PID control by microprocessor
Temp. and timer setting:	Digital setting by ▲/▼ keys
Temp. display:	Setting temperature: Orange 5-digit LED digital display (resolution: 1°C) Temperature display: Green 4-digit LED digital display (resolution: 1°C)
Timer:	1 min. to 99 Hrs. 59 min., timer resolution 1 min. or 1 hr.
Operation function:	Fixed temperature, Quick auto stop, Auto start, Auto stop, Program (maximum 99 steps, 99 patterns, repeat operation)
Additional functions:	Power on / operation time accumulation (up to 65535 hr.), calendar (timer 24 hr.), clock (24 hr. display), calibration off-set, display of power consumption, CO₂ emissions and heater operation, power failure recovery options, user setting storage and recall
Heater circuit control:	Triac with zero cross control
Safety device:	Self diagnostic functions (sensor error , heater disconnection, triac short circuit, main relay failure disconnection, automatic overheat prevention), Key lock function, Independent overheat prevention, Electric leakage breaker
Internal dimensions WxDxH:	100 x 150 x 100 mm
External dimensions WxDxH:	376 x 404 x 515 mm
Internal capacity:	1.5L
Power source (50/60Hz):	AC115V 10A (with plug)
Weight:	~29kg

Comparison of Models

Specification :	FP-103 (1.5L, 115V) :	FP-303 (7.5L, 115V) :	FP-413 (11.3L, 220V)
Operating Temp. Range :	100~1150°C :	100°C to 1150°C :	100°C to 1150°C
Temp. Control Accuracy :	±1.0°C (at 1150°C) :	±1.0°C (at 1150°C) :	±1.0°C (at 1150°C)
Max. Temp. Reaching Time :	~90 min. :	~90 min. :	~80 min.
Heater :	Iron-chrome wire - 1.1kW :	Iron-chrome wire - 2.4kW :	Iron-chrome wire - 3.25kW
Timer :	1 min. to 99 Hrs. 59 min. :	1 min. to 99 Hrs. 59 min. :	1 min. to 99 Hrs. 59 min.
Internal Dimensions (WxDxH) :	100 x 150 x 100 mm :	200 x 250 x 150 mm :	300 x 250 x 150 mm
External Dimensions (WxDxH) :	376 x 404 x 515 mm :	446 x 504 x 565 mm :	506 x 504 x 625 mm
Internal Capacity :	1.5L :	7.5L :	11.3L
Power Source (50/60Hz) :	AC115V 10A (with plug) :	AC115V 21.5A (no plug) :	AC220V 18A (no plug)
Weight :	~29kg :	~43kg :	~51kg
Price :	$7,586.25 :	$7,883.75 :	$8,206.75

Downloads

Technical Specification Download

Operator's Manual Download

Manufacturer's List Price: $8,925.00

Typically Ships Within: 2 to 3 Business Days
