BrandTech Scientific Titrette Bottletop Burette, 10mL w/ RS232 Interface

Nominal Volume

10 ml

Partial Volumes

10, 5, and 1 ml

Accuracy (10 mL Nominal Volume)

± 10 ul

Features

Operates within Class A error limits for glass burettes, meeting DIN EN ISO 385 and ASTM 287 standards

Digital display ensures clear and precise volume readings, reducing reading errors

Microliter precision allows drop-by-drop titration with drop sizes as small as 20 uL

Automatic detection between filling and titration eliminates manual switching and reduces handling errors

Large, easy-grip hand wheels and optimized gear ratio for fast filling and sensitive dispensing

Easy Calibration technology enables quick, tool-free calibration adjustments

Optional RS232 interface allows seamless data transfer to a PC for GLP-compliant documentation

Lightweight, compact design for portability and stability without external power requirements

The BrandTech Scientific Titrette Bottletop Burette, 10mL with RS232 Interface, is designed for precise and efficient titration directly from the bottle. It operates within Class A error limits for glass burettes, complying with DIN EN ISO 385 and ASTM 287 standards. The digital display ensures accurate and clear volume readings, eliminating common reading errors and enhancing process reliability. Its microliter precision allows for drop-by-drop titration, delivering high accuracy with drop sizes as small as 20 uL. The Titrette features automatic detection between filling and titration, removing the need for manual switching and reducing handling errors. Its large, easy-grip hand wheels and optimized gear ratio enable fast filling and sensitive liquid dispensing. The horizontally and vertically adjustable titration tube offers flexibility in positioning, making it ideal for use with magnetic stirrers or various bottle sizes.

Equipped with Easy Calibration technology, the Titrette allows for quick and tool-free calibration adjustments. The burette is constructed from high-quality materials ensuring durability and chemical resistance. An amber inspection window protects light-sensitive media, and the optional RS232 interface enables seamless data transfer to a PC, supporting GLP compliance by eliminating transcription errors.

Lightweight and compact, the Titrette is highly portable and stable, requiring no external power connection. It can be easily disassembled for cleaning, maintenance, and battery replacement, making it a practical and reliable choice for precision titration in any laboratory setting.

CLICK HERE TO SHOW PRODUCT VIDEO

INCLUDED:

The BrandTech Scientific Titrette Bottletop Burette, 10mL w/ RS232 Interface includes:

> Titrette Bottle-Top Burette, for GL 45 Threaded Bottles

> 170 - 330 mm Telescoping Filling Tube

> Recirculation Tube

> 2 Batteries (AAA/UM4/LR03)

> 3 PP Bottle Adapters (GL 32, S 40, NS 29/32)

> 2 Amber Colored Light Shield Inspection Windows

> 2 m Interface Cable

> CD (Driver Software and Open RS232 Communication Protocol)

> Operator's Manual

> Manufacturer's Documentation

> 1 Year Manufacturer's Warranty

BrandTech Scientific Titrette Bottletop Burette, 10mL w/ RS232 Interface Specifications

Nominal Volume:	10 ml
Partial Volumes:	10 ml 5 ml 1 ml
Accuracy (A) ≤ ± % / ul:	0.10% / 10 ul at 10 ml 0.20% / 10 ul at 5 ml 1.00% / 10 ul at 1 ml
Coefficient of Variation (CV) ≤ % / ul:	0.05% / 5 ul at 10 ml 0.10% / 5 ul at 5 ml 0.50% / 5 ul at 1 ml
Operating Temperature:	+15°C to +40°C (59°F to 104°F)
Viscosity Maximum:	550 mm/s 2
Relative Humidity:	20% to 90%
Interface:	RS 232
Power Requirements:	2 Non Rechargable Micro-Batteries, 1.5 V (AAA/UM4/LR03)

Comparison of Models

Spec / Product:	BrandTech Scientific Titrette Bottletop Burette, 10mL w/ RS232 Interface:	BrandTech Scientific Titrette Bottletop Burette, 25mL w/ RS232 Interface:	BrandTech Scientific Titrette Bottletop Burette, 50mL w/ RS232 Interface
Nominal Volume:	10 ml:	25 ml:	50 ml
Partial Volumes:	10 ml 5 ml 1 ml :	25 ml 12.5 ml 2.5 ml :	50 ml 25 ml 5 ml
Accuracy (A) = ± % / ul:	0.10% / 10 ul at 10 ml 0.20% / 10 ul at 5 ml 1.00% / 10 ul at 1 ml :	0.07% / 18 ul at 25 ml 0.14% / 18 ul at 12.5 ml 0.70% / 18 ul at 2.5 ml :	0.06% / 30 ul at 50 ml 0.12% / 30 ul at 25 ml 0.60% / 30 ul at 5 ml
Coefficient of Variation (CV) = % / ul:	0.05% / 5 ul at 10 ml 0.10% / 5 ul at 5 ml 0.50% / 5 ul at 1 ml :	0.025% / 6 ul at 25 ml 0.05% / 6 ul at 12.5 ml 0.25% / 6 ul at 2.5 ml :	0.02% / 10 ul at 50 ml 0.04% / 10 ul at 25 ml 0.20% / 10 ul at 5 ml
Power Requirements:	2 Non Rechargable Micro-Batteries, 1.5 V (AAA/UM4/LR03):	2 Non Rechargable Micro-Batteries, 1.5 V (AAA/UM4/LR03):	2 Non Rechargable Micro-Batteries, 1.5 V (AAA/UM4/LR03)
Price :	$2,048.20 :	$2,048.20 :	$2,048.20

Downloads

Technical Specification Download

Operator's Manual Download

Series Brochure Download
