MP915C 6-inch Microwave Plasma Chemical Vapor Deposition (MPCVD) System

The MP915C MPCVD System is a cutting-edge solution for high-quality diamond growth, designed to meet the demands of both industrial and research applications. Whether you're in the semiconductor industry, jewellery industry, or advanced materials research, this system offers unparalleled performance, reliability, and versatility.

Key Advantages

Large Deposition Area: Ideal for industrial-scale production or high-throughput research.
High-Purity Diamond: Produces diamonds with exceptional purity, suitable for advanced applications.
High Growth Rate: Optimized for efficient and rapid diamond synthesis.
Non-Contamination: Ensures clean and uncontaminated diamond growth.
Precise Doping Control: Enables tailored electrical and optical properties for specialized applications.
Excellent Process Stability & Repeatability: Delivers consistent results batch after batch.
High Reliability: Built for long-term, uninterrupted operation.
Wide-Range Process Control: Flexible parameters for diverse diamond growth requirements.

Specifications

Microwave Power Options:
- Standard: 25 kW (ideal for research and small-scale production).
- Optional: Up to 75 kW (for higher growth speeds and increased production capacity).
Motorized Translation Stage: Z-axis adjustable in situ during diamond growth for precise control.
Graphical User Interface (GUI): Intuitive control with multiple screens for real-time process monitoring and parameter adjustment.
- Remote Monitoring: Internet-based control and monitoring for convenience.
- Programmable Operation: Step-by-step recipe support for automated processes.
Safety Features: Multiple levels of process and safety alarms for unattended, safe operation.
Gas Control:
- Default: 4 digitally controlled MFC (Mass Flow Controller) manifolds.
- Optional: Up to 6 MFCs for advanced gas mixing and doping control.
- Automatic Pressure Control for stable and consistent growth conditions.
Backup System: PC and electronics supported by UPS (Uninterruptible Power Supply) for uninterrupted operation.
Optical Ports: >7 optical ports for real-time monitoring and diagnostics.
Temperature Monitoring: Equipped with a 2-color IR pyrometer for accurate temperature measurement.

Why Choose the MP915C?

Proven Performance: Trusted by leading research institutions and industrial users.
Scalability: Suitable for both small-scale research and large-scale production.
Ease of Use: Intuitive GUI and programmable recipes simplify operation.
Future-Proof Design: Modular and upgradable to meet evolving needs.

What’s Included?

System Documentation: Comprehensive manuals and guides for setup and operation.
Basic Growth Recipe: We provide a starter recipe to help buyers get started quickly.
Optional Training: On-site or remote training available for new users.

New and Custom-Built Systems Available

If you’re looking for a new machine or a custom-built MPCVD system tailored to your specific needs, we can provide that too! Contact us for details on new systems, custom configurations, and additional features.

Selling Points for Buyers

Immediate Availability: No long lead times—ready for installation and use.
Cost-Effective: A high-performance system at a fraction of the cost of new equipment.
Flexible Options: Choose the power range and MFC configuration that suits your needs.
Comprehensive Support: Includes documentation, manuals, and optional training for new users.
