Used Stilmas Multiple Effect Still for Water for Injection (WFI) production and Pure Steam Generation, model Pharmastill MS 2006 HPS, capable of producing 4,390 liters/hour of WFI meeting USP/EP requirements. Serial # 12706.

From the Manufacturer:

The most advanced and efficient Multiple Effect still

This system is capable of generating from 100 to 22.000 lt/h of hot WFI, while the variable wide range production capacity allows users to easily adjust the required flow rates.

Operating principle

The Pharmastill HPS utilises an ingenious combination of the ‘Thin Falling Film’ and 'Multi-stage' principles. The process begins with the first effect being fed by an external energy source (Industrial Steam or Electrical energy). Each subsequent effect operates at a lower pressure, with pure steam generated in each stage and non-evaporated water flowing to the next stage. The pure steam is then condensed back into WFI by vapourising a new portion of feed water. Pharmastill features one pre-heater for each column, efficiently recovering the sensible heat of the distillate, along with two final exchangers. Additionally, the final condenser incorporates a degassing system. Continuous WFI conductivity monitoring ensures compliance, with any ‘out of spec’ WFI automatically discharged to the drain. On-line TOC monitoring is also possible. Plus, the production capacity is adjustable within the range of 60-100%, imply by regulating the industrial steam pressure.

Design

The plant is constructed entirely of AISI 316L stainless steel, ensuring durability and reliability. The active surface comes with standard pickled and passivated finishing, while mirror or electropolishing options are available upon request. Product (WFI) contact parts are meticulously crafted with a mechanically polished surface, achieving a smooth 0.6 microns Ra finish. Piping is orbitally welded using sanitary flanges and pharmaceutical-grade Teflon gaskets. The decontamination chamber is a completely empty column, designed for optimal inspectability. The absence of welding in this area significantly reduces the risk of corrosion, ensuring a long equipment life. Pre-heaters and exchangers are of the shell-and-tube type, with a double tube sheet execution to prevent distillate contamination. Pipes are expanded into the plates, avoiding any welding for a completely hygienic execution and increased resistance to dilatation stress. The overall construction design, combined with the described decontamination process, allows for a highly flexible equipment layout and minimises the space needed for maintenance.
