Yamato IN-604W-115V Refrigerated Incubator Programmable with Window & Shaker Power Hook Up 143L, 115V

Refrigerant

R134A

Operating Temperature Range

Ambient +10-50°C

Temperature Accuracy

±0.3°C

Features

High accuracy temperature control and temperature distribution

Inner glass door keeps temperature stable during sample observation

Designed with a large dual glass door and inner door that forms a triplex glass door for improved heat retention

Interior light for better sample visibility

Optional slide shaker table available to put in and take out samples easily

Low temperature 286L forced convection incubator applicable for low temperature tests and environmental tests. Programmable. High accuracy temperature control and temperature distribution. Inner glass door keeps temperature stable during sample observation. Operating temperature range: -10~ + 50° C

INCLUDED:

The Yamato IN-604W-115V Refrigerated Incubator Programmable with Window & Shaker Power Hook Up 143L, 115V includes:

> Power Cord

> Operator's Manual

> Manufacturer's Documentation

> 1 Year Manufacturer's Warranty

Yamato IN-604W-115V Refrigerated Incubator Programmable with Window & Shaker Power Hook Up 143L, 115V Specifications

System:	Forced air convection
Operating temperature range:	-10°C~+50°C
Temperature adjustment accuracy:	±0.3°C (refrigerator in continuous operation) / ±1.0°C (refrigerator in cycle operation)
Temp. distribution accuracy:	±1.0°C (refrigerator in continuous operation at 37°C)
Max. temp. reaching time:	20~50°C ~30min
Minimum temp. reaching time:	20~-10°C ~65min
Interior material:	Stainless steel
Exterior material:	Chrome free electronic galvanized plated steel plate chemical proof baking finish
Observation window:	---
Heat insulation material:	Styrene foam
Refrigerator:	Air-cooled fully closed compressor 300W
Refrigerator medium:	R404A
Defrosting mechanism:	Manual ON / Auto OFF, Timer operation, Cycle operation
Blower fan:	Axial fan
Heater:	Iron-chrome wire heater: 750W
Sensor:	Platinum resistance temperature detector: Pt100Ω (temp. controller), K-thermocouple (overheat prevention device)
Cable port (right side):	I.D.: 30 mm
Temperature control:	PID control
Temperature setting:	Digital setting with ▲▼ keys
Temperature display:	Measured temperature: 4-digit orange LED digital display + VFD fluorescent display
Timer / timer resolution:	0 min. ~ 999 hrs. 59 min. / 1 min.
Operation function:	Fixed temperature, auto stop, auto start, program (up to 32 steps, repeat operation)
Additional functions:	Timer function (accumulated time to 49,999 hrs), calibration off-set function, clock display
Safety device:	Self diagnostic function (Temp. sensor error, Heater disconnection, SSR short-circuit, Main relay error, Automatic overheat prevention function), Key lock, Over current ELB, Overheat prevention device
Internal dimensions W x D x H:	600 x 477 x 1000 mm
External dimensions W x D x H:	710 x 645 x 1630 mm
Internal capacity:	286L
Shelf plate load:	15kg / pc.
Shelf rest step number / pitch:	23 steps / 30mm
Power supply (50/60Hz):	AC115V 10.5A (with plug) AC220V 6A (no plug, round terminal)
Weight:	~ 120kg
Included accessories:	Shelf and brackets (stainless steel punched metal), 5 pcs. shelves / 10 pcs. brackets
Door keys:	---

Comparison of Models

Specification :	Yamato IN-604-115V :	Yamato IN-604W-115V :	Yamato IN-804-115V
Operating Temperature Range :	-10°C~+50°C :	-10°C~+50°C :	-10°C~+50°C
Temperature Adjustment Accuracy :	±0.3°C (continuous) / ±1.0°C (cycle) :	±0.3°C (continuous) / ±1.0°C (cycle) :	±0.3°C (continuous) / ±1.0°C (cycle)
Max. Temp. Reaching Time :	20~50°C ~20min :	20~50°C ~20min :	20~50°C ~30min
Observation Window :	--- :	W516 x H416mm (with key) :	---
Refrigerator Medium :	R134A :	R134A :	R404A
Cable Port (Right Side) :	I.D.: 30mm :	I.D.: 50mm :	I.D.: 30mm
Internal Dimensions (WxDxH) :	600 x 477 x 500 mm :	600 x 477 x 500 mm :	600 x 477 x 1000 mm
External Dimensions (WxDxH) :	710 x 645 x 913 mm :	710 x 645 x 913 mm :	710 x 645 x 1630 mm
Internal Capacity :	143L :	143L :	286L
Power Supply (50/60Hz) :	AC115V 9A (with plug) :	AC115V 10.5A (with plug) :	AC115V 10.5A (with plug) / AC220V 6A
Weight :	~89kg :	~89kg :	~120kg
Price :	$5,389.00 :	$5,962.75 :	$6,988.85

Downloads

Technical Specification Download

Operator's Manual Download

Manufacturer's List Price: $7,015.00

Typically Ships Within: 5 to 6 Weeks
