Features

Washing and multiple reagent dispensing system eliminates the need for multiple instruments. Efficient and multitasking, the microplate washer with peristaltic and syringe pump modules provide flexibility for benchtop or integrated automated systems
Compatible with 96-, 384-, and 1536-well plate configurations, the Dual-Action manifold has rapid wash speeds for increased efficiency in your workflow. Wash speeds for the three plate types range from 13 to 36 seconds, saving time in the wash process
Gentle processing for cell-based assays with a plate carrier that has x-y-z adjustments and flow rates that are adjustable can minimize disruption of cells. The ability to optimize parameters for the most sensitive assays can diminish disruption of sample
Magnetic and polystyrene bead washing and standard plate washing and dispensing protocols for flexible operation. Automated bead washing for 96- and 384-well plates. Compatible with Luminex xMap
Easy user maintenance with Ultrasonic Advantage automated system maintenance features. Built in ultrasonic bath and automated cleaning program dislodges and aspirates salt crystals and protein build up in the system, saving time and preventing clogging

Specifications

Automation Compatibility	BenchCel BioSpa BioStack 3rd-party
Fluid Pump Type	1 Peristaltic pump Syringe pump Diaphragm pump
Instrument Control	Local Touch-pad Computer Software
Number of Reagents	1 - 4
Processes	Full-plate wash Shaking & Soaking Reagent dispensing 4 buffer switching Optimized cell wash Parallel Dispense (4 buffer max) Ultrasonic Advantage
Supported Labware	96- to 1536-well plates
Washer/Dispenser Options	Vacuum filtration Biomagnetic separation

Return to top

How It Works

Washing and multiple reagent dispensing

There is no need for multiple instruments when you have an EL406 in the lab! The EL406 is microplate washer with peristaltic and syringe pump modules available to make it into an efficient multitasking system. For benchtop use or integrated into automated systems, the EL406 does the work of multiple instruments.

Bead washing: magnetic and polystyrene

The EL406 is a powerhouse for many standard plate washing and dispensing protocols, but it also automates more complex operations like magnetic and polystyrene bead washing workflows and is Luminex xMap compatible. Bead washing is available for 96- and 384-well microplates.

96-, 384-, and 1536-well plate compatible

The Dual-Action manifold quickly washes 96- and 384-well plates. For 1536 washing, unique aspirate and dispense manifolds rapidly dispense and aspirate across the plate. Wash speeds for the three plate types range from 13 to 36 seconds, keeping all your processes efficient.

Applications

Gentle processing for cell-based assays

Cell-based assays can be challenging to wash and too often, cell monolayers are disrupted by vigorous dispensing or overly intense aspiration. The EL406 Dual-Action manifold and plate carrier have x-y-z adjustments, and flow rates are fully adjustable to optimize parameters for even the most sensitive assays. Angled dispense tubes direct fluid flow to the well sides, further minimizing disruption.

Modularity enables application versatility

Applications for the EL406 Washer Dispenser run from simple dispense operations to full scale automation of liquid handling steps in preparation for downstream processes. Here are a few important applications of the EL406.
