Namocell Pala NI006 Single Cell Dispenser, 488 Laser/FITC single channel - AV

Internal part number 51759

Here is a Namocell Pala NI006 Single Cell Dispenser

Predecessor to:
Current model

Condition:
This Namocell Pala NI006 Single Cell Dispenser is in good working condition.

Please see the exact video and photos below.

Testing we performed:
The Namocell Pala NI006 Single Cell Dispenser passed all tests and was found to be fully functional:
Tested Power On & Initialization: PASSED
Tested Communication with Pala Software v3.6.2.1: PASSED
Tested All Plate Carrier Positions: PASSED
Tested Camera Communication & Controls: PASSED
Tested Cartridge Holder Open & Close: PASSED
Tested Sheath & Waste Valves: PASSED
Tested Onboard Air Pump: PASSED
Tested & Calibrated Sheath Bottle Level Sensing: PASSED
Tested & Calibrated Waste Bottle Level Sensing: PASSED
Tested Laser 1 (488nm Blue): PASSED

System consists of:
Namocell Pala NI006 Single Cell Dispenser (1 Laser, 3 Detectors)

Laptop with Pala Software v3.6.2.1

Power & Communication Cables

This Pala is configured with a 488nm Laser and a Detection channel for FITC. This is not a two laser system.

Configuration and Setup:
(1) Laser: 488nm Blue
Channel Filter: (Blue) 527/32, FITC, GFP, YFP
Light Scatter: Forward (FSC) & Side (TSC)
(3) Detection Channels
Sorting Modes: Single Cell Dispensing, Bulk Cell Sorting, and Target Cell Enrichment.
Sorting pressure: less than 2 psi
Dispensing Format: 96- or 384-well plate, or microcentrifuge tube
Sorting time: 1 min/96-well plate; 6 min/384-well plate
Dispensing Volume: 1 uL/cell
Minimum cell input 100
Input Sample Volume: 100 – 600 uL
Input Sample Density: 100 cells – 150M cells/mL
Initialization Time: 5 minutes
Sheath Consumption: 6.5 mL/hr
Dimensions (WxDxH): 25 x 14 x 9 in (64 x 36 x 23 cm)
Weight: 35lbs (16kg)
Power: 100 - 240 VAC. 50/60 Hz

Video Description:
The video below gives an overview of the Namocell Pala NI006 Single Cell Dispenser, and also demonstrates its functionality.

Documentation:
Datasheet: Namocell Pala NI006 Single Cell Dispenser

Brochure: Namocell Pala NI006 Single Cell Dispenser

Manual: N/A Computer Includes Instructional Videos

Parcel
50#

Please do not hesitate to contact us if you have any questions.
