SP Genevac HT Series 3i HT-6 Vacuum Evaporator

Internal part number 62038

For Sale SP Genevac HT Series 3i HT-6 Vacuum Evaporator

Fully Functional
Serviced & in Stock
Current Model
Made in 2021
Good cosmetic condition
Technical sales consultation available
WARRANTY
Includes remote instrument setup and training session

Here is what you will receive:

SP Genevac HT Series 3i HT-6 Vacuum Evaporator
Integral high-power VC7000 condenser
Sample holders (Qty.:6) check with us for available holders
External Vacuum pump p/n: nXDS6i
Standard power cable
Installation & Operation manuals

3i HT-6 Vacuum Evaporator Configuration:

Sample Capacity: up to 6 flasks/plates
Max. rotor speed: 1415 rpm
Drive system: direct drive
Max. load per swing: 1.5kg
Max. operational imbalance: 80g
Vacuum pump type: oil-free scroll
Ultimate system vacuum: <0.4 mbar
VC7000 condenser type: dual-stage vapor compression
Ultimate low temperature: -75 DegC
1_st stage: F gas: R449A/ Charge: 0.320 kg/ GWP: 1397
2_nd stage: F gas: R170/ Charge: 0.041 kg/ GWP: 5.5
Total CO2e: 0.447 tonnes
Dimensions Evaporator (WxDxH): 66x71x84 cm
Weight Evaporator: 193.3 kg

Customization/Options:

Sample holders and buckets (Please check with us to see what we have in stock)

Testing performed by our in-house service team:

The 3i HT-6 Vacuum Evaporator passed all tests and was found to be fully functional:

We confirmed the initiation of the system without any issues.
We checked the display functionality and ensured optimal clarity.
We verified the responsiveness of the touch interface.
We tested the vapor condenser’s cooling capability and achieved a temperature of -75 DegC.
We tested the centrifuge rotation up to 1,415 rpm and confirmed stable operation.
We tested the vacuum pressure and verified that it met the required specifications.

Instrument Overview:

The SP Genevac HT Series 3i HT-6 Vacuum Evaporator delivers high-capacity evaporation for demanding lab workflows.
It features a direct-drive centrifuge with stable rotation up to 1,415 rpm for uniform drying.
An efficient oil-free scroll pump provides consistent vacuum levels for safe solvent removal.
The dual-stage condenser reaches down to -75°C, trapping vapors effectively and protecting the pump.
The HT-6 Vacuum Evaporator’s compact footprint fits easily into limited bench space.
The HT-6 offers reliable performance for temperature-sensitive and multi-sample processing.

Instrument Application:

Parallel Chemistry
Post-Purification Sample Handling
Controlled Crystallization
Environmental Analysis
Metabolism & Toxicology Studies
Natural Products Research Including Flavors & Fragrances
Oligo Synthesis
Compound Handling

The Key Features:

High-capacity sample evaporation.
Condenser for cold trapping.
Touchscreen control interface.
Quiet, stable centrifuge operation.
Efficient vacuum pressure system.
Safe for heat-sensitive samples.

Additional technical info:

Datasheet: HT Series 3i HT-6 Vacuum Evaporator Datasheet
Brochure: HT Series 3i HT-6 Vacuum Evaporator Brochure

Video Overview:

About us

How we pack

Why do so many customers choose to order from us?

Our Advantage

We have experience servicing and repairing these instruments.
This instrument goes through all the described service steps before shipping. see the questions section below
We offer detailed photos and videos of the instruments you buy.
We are an approved pre-owned equipment vendor to many large US, Canadian, and EU Universities.
We are an approved pre-owned equipment vendor to many Fortune 500 US and International Biopharma companies.
Technical sales consultation available
Remote installation and instrument operation training may be available.
On-site installation may be available in the Boston Area (New England area)
US or International shipping is no problem (see the shipping tab on how we pack and feel at ease)

Our Guarantee

Warranty
You get after-sales technical support
Customer references are available
The instrument will be fully functional!
Smooth process from the initial quote to order fulfillment

This will ship via freight. Please contact us with your zip code to obtain a shipping quote.

PLEASE NOTE THAT THE QUESTIONS BELOW ARE ANSWERED IN MORE THOROUGH DETAIL ON OUR WEBSITE

Q: Can I view this instrument in person at your facility or do a live Zoom demo before it is shipped to me?
A: We can accommodate both in-person or Zoom demos.

Q: What about the warranty?
A: The instrument comes fully warranted for both parts and labor.

Q: Do you offer installation, service, etc?
A: We offer remote installation and training packages to familiarize you with this instrument.

Q: What should I watch out for when buying a used/pre-owned instrument from another lab?
A: Ensure that the instrument is in good working condition with no damage or wear that could affect its performance. Ask for details about testing steps performed, video demo, and test screenshots.

Q: Do you have more than one of these instruments on hand?
A: We generally carry multiple instruments on hand, along with a variety of spare parts.

Q: This procurement is for a University or College. Are purchase orders with NET terms accepted?
A: We accept purchase orders from all major US and Canadian universities.

Q: How fast will you ship?
A: We can ship within a few days to two weeks. Shipping time depends on the current demand for our instruments. Members of our sales team will be able to offer current delivery estimates.

Q: Will my instrument be insured during shipping?
A: Absolutely! We insure all our shipments as long as we are the shipper. If a customer ships on their account, they handle insurance.

Q: How do you pack? Have you previously packed and shipped the fragile laboratory instruments?
A: We have extensive experience shipping high-end and complex laboratory instruments in the US and Internationally.

Q: Do you ship Internationally?
A: Yes! We have shipped to multiple continents and over 30 countries.

Q: How much will I save buying it pre-owned, and is it worth it?
A: When compared to buying a new instrument, you will save 60% or more and have plenty of funds left over for an additional instrument or two.
