Yamato Mechanical Convection Ovens Yamato DKN series Yamato DKN402C/412C Yamato DKN602C/612C DKN812C Yamato DKN912C NEW

Specifications

	DKN402C/412C	DKN602C/612C	DKN812C	DKN912C
Performance
Circulation method	Forced circulation
Operating temperature range	Room temp.+10 to 260°C	Room temp.+10 to 210°C
Temp. control accuracy	±1.0°C (at 210°C)
Temp. uniformity	±2.8°C (at 260°C)	±2.5°C (at 210°C)
Max. temp. reaching time	Approx. 80 min.	Approx. 60 min.
Components
Interior material	Type 304 Stainless steel
Exterior material	Cold rolled steel plate with melamine resin baking finish
Heat insulating material	Rock wool	Glass wool
Heater	SUS 316 pipe heater
Fan type	1.2 kW	1.5 kW	1.5 kW×2	1.8 kW×2
Scirocco fan
Motor, Condenser type	10 W	30 W	10 W×2
Exhaust port	30 mm l.D.×2 pcs. (top)	30 mm l.D.×2 pcs. (back)
Observation window	250×280mm	NA
Controller
Temp. controller	3 patterns program controller, PlD control by microprocessor
Temp. setting method	Digital setting with key
Temp display method	Measurement temp. : Digital display by green LED Setting temp. : Digital display by red LED
Timer	1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs. 50 min.
Operation function Program mode	Fixed temperature operation, Program operation, Auto start, Quick Auto-stop, Program operation : 3 pattern, 30 steps (30 steps×1, 15 steps×2, 10 steps×3) Pattern repeat function
Additional functions	Calibration off-set, key-lock, power failure compensation
Heater circuit control	SSR control
Sensor	K-thermocouple
Safe Device
Safety countermeasures	Failure of sensor, heater SSR, memory, internal communication, temperature inputting circuit, automatic overheating prevention device, overheating prevention device, measurement temperature, circuit breaker, overheat prevention device
Standard
Internal dimensions (W×D×Hmm)	450×450×450	600×500×500	600×500×1,000	1,070×500×1,000
External dimensions(W×D×Hmm)	560×601×820	710×651×870	710×651×1,608	1,180×651×1,616
Internal capacity	90 L	150 L	300 L	535 L
Shelf plate with standard load	Approx. 15kg/piece
Shelf rest step number	9 steps	12 steps	29 steps	29 steps×2
Shelf rest pitch	30 mm
Power source 50/60Hz	DKN-402C: 115V single phase, 11A	DKN-602C: 115V single phase, 12.5A	220V single phase, 15A	220V single phase, 18A
DKN-412C: 220V, 6.5A	DKN-612C: 220V, 7A
Weight	Approx. 50 kg	Approx. 65 kg	Approx. 110kg	Approx. 190 kg
Accessories
Shelf plate	Stainless steel, 2 pcs.	Stainless steel, 4 pcs.	Stainless steel, 8 pcs.
Shelf bracket	4 pcs.	8 pcs.	16 pcs.
Optional Accessories
	Stand / Fitting for stacking / Additional shelf plate / Cable hole (25/50mm) / External communication terminal / Temp. output terminal (4 to 20mA) / Time up out-put terminal / Out-put terminal for alarm device.
