For Sale Zeiss Axiovert 200m Inverted Fluorescence Phase Contrast Microscope Pred Zeiss Observer 7

Fully Functional
Serviced & in Stock
Customized to your requirements
Includes new fluorescence filters
Technical sales consultation available
Continental USA/Canada 180 DAYS WARRANTY & 90 DAYS INTERNATIONAL
Extend to 1-Year warranty in the USA/Canada for $2995.00, EU/UK $5495.00, World $6895.00
Multi-year warranty contracts are available
Includes remote microscope training session and software overview
More info about our Microscopy Capabilities or view the Microscope Buying Guide

The Predecessor to Zeiss Observer 7 Inverted Fluorescence Microscope

Save around $50,000.00+ versus buying a new one! Get the full 1-year warranty or multi-year agreement.

This is what you will receive before customizing this microscope:

Standard Zeiss Axiovert 200m Microscope Configuration:

Microscopy Techniques:

Brightfield with Phase Contrast and Fluorescence Microscopy

Microscope Base:

Zeiss Axiovert 200m Base
with a Motorized(Automated) Z-Axis Drive

Microscope Head:

Binocular Head
Two Eyepieces

Fluorescence Light Path:

Zeiss fluorescence lightpath built into the base

Fluorescence Illumination:

100 Watt full spectrum HBO lamp
100 Watt full spectrum HBO power supply

Fluorescence filter cube turret:

Motorized 5-position filter cube turret

Fluorescence filters:

Three empty filter cubes
Three Brand New filter sets of either DAPI, FITC, Texas Red or CY3

Brightfield Light Path:

Illumination Tower

Brightfield Illumination:

100 Watt halogen light source
100 Watt halogen power supply built into the base

Objective Turret:

Motorized 6-position objectives turret

Objectives:

5x/0.15 Plan-Neofluar
10x/0.30 Plan-Neofluar Ph1
20x/0.40 Plan-Neofluar

Condenser:

Motorized condenser
Ph1 Light Ring

Stage:

Mechanical Stage

Camera ports:

100% Eyepiece, 0% Camera
20% Eyepiece, 80% Camera
0% Eyepiece, 100% Camera

Camera adapter:

1x C-mount adapter

Camera:

CMOS USB 3.0 10MP Camera

Computer & Software:

Dell laptop computer with Windows 10
Micromanager w/ImageJ analysis software
Camera software

Accessories:

Necessary power and communication cables

This configuration includes any 3 of these new filter sets.

New filter set - DAPI (EX: 365/28nm, DM: 405nm, EM: 445/50nm) (Dye compatibility: DAPI/Hoechst/AlexaFluor 350)
New filter set - EGFP/FITC/Cy2 (EX: 475/30nm, DM: 500nm, EM: 530/40nm) (Dye compatibility: EGFP/FITC/Cy2/AlexaFluor 488)
New filter set - TRITC/Cy3/Dsred (EX: 545/20nm, DM: 562nm, EM: 605/60nm) (Dye compatibility: TRITC/Cy3/RFP/Rhodamine/AlexaFluor 546)
New filter set - Texas Red (EX: 560/20nm, DM: 585nm, EM: 630/40nm) (Dye compatibility: Texas Red/mCherry/AlexaFluor 594)
New filter set - Cy5 (May require an upgraded light source) (EX: 630/50nm, DM: 662nm, EM: 695/50nm) (Dye compatibility: Cy5/AlexaFluor 647/Draq5)

Automated/motorized capabilities of this microscope:

Installed automation/motorized components:

Motorized lightpath
Motorized/automated Z-Axis Drive
Motorized filter cube turret
Motorized objective(nosepiece) turret
Motorized condenser

Benefits of motorized/Automated Z-Axis drive:

Automatic parfocality adjustment
The ability to recall previously saved focus levels
Automated management of Z positioning/ Fine-coarse control

This microscope's imaging capabilities:

Imaging software highlights:

Ability to take still images and live videos of your samples
Display, annotate, edit, calibrate, measure, analyze, process, print, and save raster
Variable linear measurements such as line segment, radius values, and others
Open source Micromanager Multi-dimensional Image acquisition & automation software capabilities
Multi-frame (Time lapse/Image acquisition over time)
Multi-slice (Z coordinate/Z Stacking)
*Multi-position (XY coordinate/Stitching/Mosaic) – only available when equipped with a motorized XY Stage

We can customize this microscope to fit your requirements:

Add Microscopy Techniques (In addition to installed Brightfield and Fluorescence)

Phase Contrast, DIC, or Polarization Add-on Components may be added (subject to availability)

Increase Maximum Magnification and Image Quality:

Microscope can be configured for magnification between 40x and 1000x (with 10x Eyepieces)
We can add standard higher magnification Zeiss microscope objectives
We can add high-end Zeiss Apochromat objectives

Enhance fluorescence capabilities by adding/changing filters and upgrading light sources.

Additional filter cubes
Additional filter sets to match your fluorochromes.
Xenon, Metal Halide, or LED Fluorescence microscope light sources

We will also ensure the fluorescence light source matches your selected filter sets.

Enhance imaging capabilities:

We offer various advanced CCD, sCMOS, and EMCCD camera options for higher-quality images.

Add other Motorized/Automation Capabilities:

In addition to installed motorized capabilities, the microscope can be configured

Motorized Stage, Motorized high-speed shutter

We can configure it to work with the sample medium you need:

Slide, Petri dish, microplate, etc
It may also be set up with a motorized XY stage for multi-slide or full microplate scans.

Commonly Requested Customer Upgrades

High-End CCD, sCMOS Cameras
LED or Metal Halide Fluorescence Light Sources
Phase Contrast, Polarization, or the DIC configurations
Higher Magnification Objectives
Higher performance Fluor or APO objectives
Motorized XY Stage (stage, controller, joystick)

We are excited to help build and configure the right microscope for you!

Zeiss Axiovert 200m Fluorescence Microscope Overview

(Final microscope capabilities will depend on the modifications you request)

An inverted Zeiss microscope is optimized for live cell imaging with an ergonomic design for comfortable, prolonged use.
Its adaptable light path ensures optimal illumination for diverse imaging techniques.
Equipped with high-performance Zeiss optics to deliver sharp, high-contrast images across all magnifications.
It can be paired with various fluorescence illumination options, such as Metal Halide, Xenon, or LED.
Additionally, setup for Phase Contrast Imaging
The included motorized condenser allows for rapid and precise placement of any installed DIC prisms or Phase Contrast Angular rings.
Motorized Z-axis, objective, and filter cube turrets offer an extended range of applications.
Fully configured with imaging software for comprehensive image acquisition and analysis.
Modular design allows for easy upgrades and integration of wide-ranging accessories like cameras and light sources.
It can be configured for advanced imaging, such as DIC, which offers 3D-like images.
Superb reliability that you would expect from Zeiss microscopes.
The predecessor to Zeiss Observer 7, it is very similar in capabilities and offers superb choice while saving your budget.

Suited for the following applications as configured:

Fluorescence microscopy: Ideal for fluorescent labeling and imaging of cells and tissues.
Material science research: Suitable for examining material properties and structures.
Biological research: Essential for cellular structure, function, and behavior studies.
Pharmacological studies: Facilitates the investigation of drug effects on cells and tissues.
Biotechnology applications: Enables genetic engineering and molecular biology research.
Educational purposes: Serves as a teaching tool in universities and research institutes.
Phase contrast: Enhances visibility of transparent specimens without staining.

Other potential applications:

DIC: Enhances visibility of transparent specimens without staining.
Time-lapse photography: Captures sequential images to monitor changes over time.
Multi-dimensional imaging: Allows for the acquisition of images in multiple planes and dimensions.
Quantitative analysis: Supports measurements and quantification of specimen features.
High-resolution imaging: Provides clear, detailed images for in-depth analysis of samples.
Live cell observation: Enables detailed study of live cell dynamics in real-time.

Brochure: Zeiss Axiovert 200M Inverted Fluorescence Microscope
Manual: Zeiss Axiovert 200M Inverted Fluorescence Microscope

Video Overview:

Check out our microscopy capabilities:

https://www.bostonind.com/our-microscopy-capabilities

ABOUT US...

HOW WE PACK

Why do so many customers choose to order from us?

Our Advantage

We make sure to match the microscope capabilities to your requirements.
We have experience servicing and repairing these microscopes.
This microscope goes through an extensive set of service steps before shipping.
We offer detailed photos and videos of the microscopes you buy.
We are an approved pre-owned equipment vendor to many large US, Canadian, and EU Universities.
We are an approved pre-owned equipment vendor to many Fortune 500 US and International Biopharma companies.
Many upgrade and repair parts are in stock.
Remote installation and microscope operation training are available.
On-site installation may be available in the Boston Area (New England area)
Expert US or International shipping is available (see the shipping tab on how we pack and feel at ease)

Our Guarantee

Warranty
An extended warranty may be available.
You get after-sales technical support.
Customer references are available.
The microscope will be complete and working!
Smooth process from the initial quote to order fulfillment.

*SM* Small Crate
200#

PLEASE NOTE QUESTIONS BELOW ARE ANSWERED IN MORE THOROUGH DETAIL ON OUR WEBSITE

Q: I am not 100% sure about the configuration I need, can your team assist me with selecting the right microscope for me?
A: Absolutely, we can start with your application, samples, or challenge to assist you in selecting the right configuration and the right microscope for you.

Q: Can you make the necessary modifications to the standard configuration to fit my application?
A: Certainly, we carry a large variety of upgrade components to ensure the final microscope configuration will fit your application

Q: What steps do you take to verify, service, and confirm the functionality of this Microscope?
A: Each microscope goes through extensive service to ensure it performs to specification.

Q: Can I view this microscope in person at your facility or do a live Zoom demo before it is shipped to me?
A: We can accommodate both in-person or Zoom demos.

Q: What about the warranty?
A: The microscope comes fully warranted for both parts and labor.

Q: Do you offer installation, service, etc?
A: We offer remote installation and training packages to get you familiar with this microscope

Q: What should I watch out for when buying a used/pre-owned microscope from another lab?
A: That it has no missing, broken, or incorrect parts for your application, any mechanical or motorized components have been serviced and lubricated, controller issues, good quality filter cubes, proper and undamaged objectives, and most importantly no dust in the light path or objectives.

Q: Do you have these and other microscopes on hand?
A: We carry this and many other microscopes from Nikon, Zeiss, Olympus, and Leica.

Q: I am from the University or College, do you accept Purchase Orders?
A: We accept purchase orders from all major US and Canadian universities.

Q: How fast will you ship?
A: We can ship within 2-3 days to about 2 weeks, depending on the final configuration required.

Q: Will my instrument be insured during shipping?
A: Absolutely! We insure all our shipments as long as we are the shipper. If a customer ships on their account, they handle insurance.

Q: Have you packed and shipped microscopes in the past?
A: We have extensive experience in safely shipping high-end and complex microscopes all over the world.

Q: Do you ship Internationally?
A: So far, we have shipped to almost every continent and over 30 countries.

Q: How much will I save buying it pre-owned, and is it worth it?
A: When compared to buying a new one, you will save up to 60% to 80% and have plenty of funds left over for an additional instrument or two.
