Overview of Thermo Scientific TSU Series TSU600D Ultra-Low Temperature ULT Freezer

The Thermo Scientific TSU600D freezers are designed for ultimate sample protection and combine vacuum panel insulation with environmentally-friendly, water-blown foam insulation for maximum sample-to-vial footprint storage. The TSU600D reaches a temperature range from -50 degrees Celsius to -85 degrees Celsius at 32 degrees Celsius (90 degrees Fahrenheit) ambient. It can hold up to 815 liters or 28.8 cu. ft. 600 Standard 2-inch boxes.

View in stock used ultra-low temperature freezers for sale here. Need assistance? Get in touch with us today.

Thermo Scientific TSU600D Features

Here are the key features of the TSU Series Freezer:

• Performance: The TSU Series has an outstanding temperature uniformity and peak variation from setpoint. The energy-savings mode can save up to 15% while still offering tightly-controlled cabinet temperature and excellent door-opening recovery.

• Ease and Safety: The TSU Series has an innovative, touch-screen control panel that allows 24/7 monitoring of the freezer's health. It also provides access to a detailed event log with a built-in USB port that enables easy downloading of event log reports or exchange of data and settings from one freezer to another. This series also can store up to 15 years worth of temperature and event data with an on-board computer.

Thermo Scientific TSU600D ULT Freezer Specifications

Manufacturer	Thermo Fisher Scientific
Product line	TSU Series
Model No.	TSU600D
Item No.	162DT4B01A
Serial No.	1118019801170803
Mfg. date	2017
Type	Ultra-Low Freezer, Upright
Storage volume	815 liters (28.8 cu. ft.), 600 standard 2” boxes
Temperature range	-50°C to -85°C @32°C(90°F) ambient
Max. capacity per shelf	245 lbs (110 kg)
Defrost method	Manual defrost
Remote alarm terminals	RS485/4-20mA output
Power rating	208/230, 60Hz, 9.0A, 1Ph
Interior dimensions (W x D x H)	34.4 x 28.3 x 51.2 in
Exterior dimensions (W x D x H)	43.6 x 37.6 x 78 in
Weight	854 lb (388 kg)

Our Testing Process

1. Upon arrival, the freezer undergoes a thorough visual inspection to assess its overall condition.

2. The interior and exterior of the unit are cleaned using a dry ice blasting method to remove buildup and contaminants without damaging components.

3. The freezer technician checks the ambient pressures of the high and low side compressors (if applicable) and performs an amperage check to confirm proper electrical draw. Compressors are also monitored for excessive noise and heat. The freezer is then powered on and observed to ensure it is cooling in accordance with the manufacturer's specifications.

4. Refrigeration lines are reinsulated to enhance thermal efficiency and prevent condensation.

5. Door seals and other essential components are inspected and replaced as necessary to maintain proper sealing and functionality.

6. In air-cooled units, the condenser and fans are responsible for dissipating heat. Fan alignment is checked, the condenser is inspected and cleaned to ensure adequate airflow, and the air filter is cleaned or replaced as required.

7. The backup display battery is tested for proper voltage and replaced if necessary to ensure uninterrupted display functionality during power loss.

8. After the unit has been running for a set period, the lowest interior temperature is recorded and verified to ensure it falls within the manufacturer's specified guidelines.

NLS' Standard Thermo Scientific TSU Series ULT Freezer Accessories

• Shelves• Power cable• 90-Day to 1-Year Warranty

Our Ultra-Low Temperature Freezer Technician Checklist

At New Life Scientific, our technicians test each device thoroughly before shipping to verify performance and functionality. After our freezer technician finishes the initial testing process, this ULT Freezer Technician Checklist is filled out to record the important information gathered throughout the repair process. This checklist will be available publicly after the unit has undergone tech completion and is ready for the customers.

Thermo Scientific TSU Series ULT Freezer Applications

• Biological Sample Preservation - For long-term storage of DNA, RNA, proteins, and enzymes. ULT Freezers also help in storage of temperature-sensitive vaccines such as mRNA COVID-19 vaccines and investigational drugs for clinical trials.

• Clinical and Hospital Use - For long-term storage of patient samples for diagnostics and research and organ and tissue storage for transplant or regenerative medicine research.

• Forensic Science - Cold storage to prevent degradation of biological materials.

• Environmental and Ecological Research - Preservation of ice cores, soil samples, and microorganisms from extreme environments and for climate change studies.

Contact New Life Scientific Today for Additional Information

Our team can help you decide whether the TSU Series’ capacity and features align with your processing needs. Contact us today if you have questions or need additional specifications. You may also:

• Live chat with us by clicking on the icon at the lower right of your screen.

• Email us at cs@newlifescientific.com

• Call us at (567)-210-2838
