This refurbished Waters ACQUITY Arc Sample Manager FTN-R P/N: 186017001 is fully tested and in working condition

Including:

Waters ACQUITY Arc Sample Manager FTN-R P/N: 186017001
Installation guide and user documentation
Power and communication cables
90 Days Warranty

Overview:

The Waters™ ACQUITY™ Arc™ System is the only available LC system with regulatory compliant-ready hardware and software for both HPLC and UHPLC separations in one instrument. With an expanded range of column manager options enabling up to 15-column switching from 4 °C to 90 °C and Arc Multi-flow path™ technology, the ACQUITY Arc System allows you to generate new methods and modernize legacy HPLC methods faster than ever before.

Specifications:

Injection volume range	0.1 to 50.0 µL as standard; up to 1000.0 µL with optional extension loops
Sample capacity	768 [2x 384-well plate]; or 96 [2-mL vial holders] Any two of the following: • 48-position, 2.00-mL vial holder (total 96 vials) • 96-well plate • 384-well plate • 48-position, 0.65-mL micro-centrifuge tube plate • 24-position, 1.50-mL micro-centrifuge plate
Sample compartment temperature	4.0–40.0 °C, settable in 0.1 °C increments (optional)
Temperature accuracy	±0.5 °C at the sensor
Temperature stability	±1.0 °C at the sensor
Injection needle wash	Integral, active, and programmable
Minimum sample required	3 µL residual using total recovery 2-mL vials
Accuracy (aspiration)	±0.2 µL
Linearity	>0.999; 0.2 – 50.0 µL
Precision	<1.0% RSD from 0.5 to 0.9 µL <0.5% RSD from 1.0 to 4.9 µL <0.25% RSD from 5.0 to 1000.0 µL
Sample carryover	≤0.002% [Caffeine] under UV conditions
Advanced capabilities	Auto-dilution, auto-addition, load ahead
Primary wetted materials	316L stainless steel, gold-plated stainless steel, polyimide, PEEK blend, DLC
