Yamato SN-310 Autoclave without Dryer 32L

Manufacturer: Yamato Scientific America

Model: SN310C

Condition: New. Ships directly from the manufacturer.
Guarantee: Yamato's 15 Day Money Back Guarantee
Warranty:1 Year manufacturers warranty

Estimated lead time: In stock: Typically ships in 5 business days from acceptance of order. Out of stock: Ships in 3 months.

Includes:

1 Yamato SN310C Autoclave without dryer (220V no plug; round terminal)
2 pcs. stainless steel mesh basket (ø262 x D204mm), OSM70
1 Vapor cup
1 Drain bottle
1 Drain board
Chemical indicator 1 set (30 pieces),
1 Filter

Features

Programmed one touch buttons for common sterilization process; Manual, Melt -> Warm, Sterilize -> Warm, Sterilize/Liquid, Sterilize/Normal.
In addition to default sterilization programs, custom-programming can be saved for repeat uses.
Two sensor ports are provided as standard on the chamber.
With the optional mounted sample temperature sensor, you can precisely maintain a desired temperature for the samples to ensure thorough sterilization.
The drain bottle is located in pront for easy access and drain water level can be monitored without opening the lakinet door.
Up to 20 errors can be saved to memory.
Internal Capacity: 1.1 cu. ft. (32L)
Effective dimensions of chamber: 300 (inner diameter) 445 (depth) mm
Range of working temperatures: 45-60C for preheating, 40-60C for keep warm, 65-100C for melting, 105-135C for sterilization
Max. working pressure: 0.255MPa
Ambient temperature: 5 - 35C
Heater: 100V, 1.6kW (800W 2 units)
Cooling fan: Axial fan motor
Temperature setting: control and display PID control by microprocessor, digital setting (by UP/DOWN keys) and display
Timer and its resolution: 0 or 1 minute to 99 hours 59 minutes in increments/decrements of 1 minute

Specifications

MODEL	SN300C SN310C	SN500C SN510C
System	Automatic high-pressure steam sterilization
Operating Temperature Range	45~135°C
Max. Working Pressure	0.255MPa
Ambient Temperature	5~35°C
Lid	Manual upward opening with an interlock for safety
Heater	100V, 800W x 2 units	100V, 950W x 2 units
Exhaust Valve	One exhaust valve and one slow release valve
Connection Ports For Optional Accessories	Total 3 ports. Female thread for sample temp. sensor (1/4" ), Female thread for chamber temp. sensor (1/4" ), Female thread pressure sensor (branching from the solenoid valve tubing)
Cooling Fan	Axial fan motor
Temp. Controller	PID control by microprocessor
Temp. Display / Setting	Digital display / digital setting by ▲▼ keys
Timer / Timer Resolution	0 or 1 min. to 99 hrs 59 min. / 1 min.
Operation Mode	Instrument sterilization course, liquid sterilization course, sterilization and keep warm course, melting and keep warm course, customer-programmed course
Other Functions	Key locking, presetting, saving, preheating, forced cooling, sample temperature sensor (option), pattern locking, up to 20 error log saving, display of accumulated working time / present time, ON-OFF beeping setting
Safety Device	Sensor failure detection, SSR short-circuit, broken heater wire, prevention of idle heating (liquid expansion type), alarm against the absence of a drain bottle, failure in locking the lid, memory error detection, pressure relief valve (0.255 MPa)
External Dimensions (WxDxH)	460 x 590 x 848 mm	460 x 590 x 1068 mm
Internal Dimensions Of Chamber	ø300 x D445 mm	ø300 x D665 mm
Internal Capacity	32L	47L
Weight	~75kg	~85kg
Power Source	AC100~120V (15~12.5A) (no plug, round terminal) AC200~240V (10~8.5A) (no plug, round terminal)	AC100~120V (23.5~19.5A) (no plug, round terminal) AC200~240V (12~10A) (no plug, round terminal)
Included Accessories	2 pcs. stainless steel mesh basket (ø262 x D204mm), OSM70	3 pcs. stainless steel mesh basket (ø262 x D204mm), OSM70
Included Accessories	Vapor cup x 1, Drain bottle x 1, Drain board x 1, Chemical indicator 1 set (30 pieces), Filter x 1

Accessories

Also available with 100-120V
Mesh type basket
Mesh type basket with stacking fitting
Mesh type basket with a mesh shelf
Stainless solid basket
Stainless bucket
Chamber temperature sensor
Sample temperature sensor
Pressure gauge
Recorder
External alarm output terminal
Temperature output terminal
Time-up output terminal
